ZU 2014 K (80455) - Snapper Zero-Turn Mower, Unistat Drive, 20hp Parking Brake Assembly Parts Diagram

Zero-Turn Mower, Unistat Drive, 20hp

Parking Brake Assembly Parts Diagram

  • Title
1

Snapper 7062329

BALL VALVE, 1/4 NPTF

$

$

Not available

2

Snapper 7062330

BRACKET, BRAKE VALVE MTG.

$

$

Currently unavailable

3

Snapper 7015617

HOSE CLAMP, 1/4 HH SCREW 1/4 MIN.

Note: Was 79569

$

$

Currently unavailable

4

Snapper 7062331

HOSE, 3/8 ID X 15" LONG

$

$

Currently unavailable

?5

Snapper 7062332

HOSE, 3/8 ID X 38" LONG

$

$

Currently unavailable

6

Snapper 7062333

TEE, HOSE BARB, 3/8 X 3/8 X 3/8

$

$

Currently unavailable

7

Snapper 7079794

HOSE BARB 90 EL 1 /4 NPTM X 3/8
(Superseded to 7079794YP)

$15.99

$

Usually ships in 2-12 days

0

8

Snapper 7062334

LOCK WASHER, 1/4 EXTERNAL STAR

$

$

Currently unavailable

9

Snapper 7091084

SCREW, 1/4 X 3/8 SELF-TAP
(Superseded to 703583)

Note: Was 62249

$4.99

$

In Stock, Qty 20+

0

10

Snapper 7062335

SCREW, #10-24 X 5/16, RND HEAD

$

$

Currently unavailable

11

Snapper 7062232

LOCK WASHER SPLIT STL, # 10-32

$

$

Currently unavailable
