ZTH 5225 A (968999154) - Husqvarna 52" Zero-Turn Mower (2000-06) Park Brake Assembly Parts Diagram

52" Zero-Turn Mower

Park Brake Assembly Parts Diagram

  • Title
1

Husqvarna 539102799

BRAKE SHAFT

$

$

Not available

2

Husqvarna 539977703

3/8 X 1 1/8 CLEVIS PIN

$5.99

$

In Stock, Qty 11

0

3

$24.99

$

In Stock, Qty 11

0

4

Husqvarna 539990365

1/8 X 3/4 COTTER PIN
(Superseded to 876020412)

$6.49

$

In Stock, Qty 20+

0

5

Husqvarna 539990155

3/8F HEX NUT

$4.99

$

In Stock, Qty 16

0

6

$23.99

$

Usually ships in 3-10 days

0

7

Husqvarna 539102821

TRUNION PIN

$5.99

$

Usually ships in 3-10 days

0

8

Husqvarna 539990517

3/8 FLAT WASHER

$3.99

$

Usually ships in 3-10 days

0

$

$

Not available

10

Husqvarna 539990289

3/8F CENTERLOCK NUT

$3.99

$

Usually ships in 3-10 days

0

11

Husqvarna 539103578

BRAKE BRACKET, LEFT

$103.99

$

Usually ships in 3-10 days

0

11

Husqvarna 539103579

BRAKE BRACKET, RIGHT

Note: (NOT SHOWN)

$103.99

$

Usually ships in 3-10 days

0

12

Husqvarna 539990209

5/16C X 1 HEX CAP SCREW

$1.99

$

Usually ships in 3-10 days

0

13

Husqvarna 539976998

1/4 - 28 ZERK
(Superseded to 596899901)

$3.49

$

In Stock, Qty 20+

0

14

Husqvarna 539990184

5/16C CENTERLOCK NUT

$3.99

$

Usually ships in 3-10 days

0

15

Husqvarna 539102455

3/8 X 1-1/2 CLEVIS PIN

$3.99

$

Usually ships in 3-10 days

0

16

Husqvarna 539102822

BRAKE BAND

$

$

Not available

17

Husqvarna 539103527

WHEEL MOTOR

$

$

Not available

18

Husqvarna 539101331

1/2C NYLOC NUT
(Superseded to 596135601)

$4.99

$

In Stock, Qty 20+

0

19

Husqvarna 539101332

1/2C X 2 3/4 HEX CAP SCREW

$5.99

$

In Stock, only 3 left!

0

20

Husqvarna 539101465

KEY, #808 WOODRUFF

$

$

Not available

25

Husqvarna 539102456

HUB WITH BRAKE DRUM

$

$

Not available

26

Husqvarna 539990297

COTTER PIN

$

$

Not available

27

Husqvarna 539101468

HEX SLOTTED NUT

$3.99

$

Usually ships in 3-10 days

0

28

Husqvarna 539104582

WHEEL ASSEMBLY

$

$

Not available

$103.99

$

Usually ships in 3-10 days

0

28

Husqvarna 539912234

VALVE STEM

$6.49

$

In Stock, Qty 20+

0

28

Husqvarna 539102736

TIRE
(Superseded to 539119519)

$

$

Not available

29

Husqvarna 539101173

1/2F LUG NUT

$

$

Not available

30

Husqvarna 539102804

BRAKE LEVER

$

$

Not available

31

$

$

Not available

$3.99

$

In Stock, only 3 left!

0

33

Husqvarna 539102913

BRAKE ROD, LONG

$7.99

$

Usually ships in 3-10 days

0

34

Husqvarna 539990134

3/8C X 3/4 HEX CAP SCREW

$4.99

$

Usually ships in 3-10 days

0

35

Husqvarna 539102797

FLANGE BEARING

$9.49

$

Usually ships in 3-10 days

0

36

Husqvarna 539101836

BRAKE STOP

$3.99

$

Usually ships in 3-10 days

0

37

Husqvarna 539990588

3/8C X 2 HEX CAP SCREW

$4.99

$

In Stock, Qty 10

0

38

Husqvarna 539990546

3/8C CENTERLOCK NUT

$

$

Not available

39

Husqvarna 539990637

3/8C X 2-1/2 HEX CAP SCREW

$1.99

$

Usually ships in 3-10 days

0

40

Husqvarna 539102454

E RING 3/4

$3.99

$

Usually ships in 3-10 days

0

41

Husqvarna 539990613

3/8C WHIZ NUT

$3.99

$

Usually ships in 3-10 days

0
