ZT Avenger - Bad Boy Zero-Turn Mower (2025) TRANSAXLE SUB ASSEMBLIES Parts Diagram

Zero-Turn Mower

TRANSAXLE SUB ASSEMBLIES Parts Diagram

  • Title

1

Bad Boy 022-2032-00

20x10-8 4P A2103 Tire Only

$113.99

$

Usually ships in 4-7 days

0

2

Bad Boy 022-2033-00

8 x 6.375 4H Black Wheel Only

$

$

Not available

3

Bad Boy 034-9080-00

Transaxle Spring

$15.99

$

In Stock, Qty 7

0

4

Bad Boy 050-2070-00

2021 ZT/Maverick Transaxle Fan/Pulley Kit

$90.99

$

In Stock, only 4 left!

0

5

Bad Boy 050-2076-00

ZT Transaxle Wheel Hub

$96.99

$

Usually ships in 4-7 days

0

6

Bad Boy 050-2012-00

Transaxle Wheel Studs/ Drum Brake Studs

$5.99

$

In Stock, Qty 20+

0

7

Bad Boy 050-8010-00

2021 ZT/Maverick Transaxle Seat Kit (ZT-2800)

$124.99

$

In Stock, only 2 left!

0

8

Bad Boy 063-1050-00

ZT Hydraulic Filter

$24.99

$

In Stock, Qty 20+

0

9

Bad Boy 034-9080-00

Transaxle Spring

$15.99

$

In Stock, Qty 7

0

10

Bad Boy 050-2070-00

2021 ZT/Maverick Transaxle Fan/Pulley Kit

$90.99

$

In Stock, only 4 left!

0

11

Bad Boy 050-2076-00

ZT Transaxle Wheel Hub

$96.99

$

Usually ships in 4-7 days

0

12

Bad Boy 050-2012-00

Transaxle Wheel Studs/ Drum Brake Studs

$5.99

$

In Stock, Qty 20+

0

13

Bad Boy 050-8010-00

2021 ZT/Maverick Transaxle Seat Kit (ZT-2800)

$124.99

$

In Stock, only 2 left!

0

14

Bad Boy 063-1050-00

ZT Hydraulic Filter

$24.99

$

In Stock, Qty 20+

0
