Z-Wing 48 (53AI5BBY750) - Cub Cadet 48" Tank Zero-Turn Mower, 23hp Kohler Brake Assembly Parts Diagram

48" Tank Zero-Turn Mower, 23hp Kohler

Brake Assembly Parts Diagram

  • Title

1

Cub Cadet 00005530

Flat Washer, 3/8 Nylon
(Superseded to 736-04070)

$

$

Not available

2

Cub Cadet 00009812

Flat Washer, 5/16

$

$

Not available

3

Cub Cadet 00011446

Cap Screw, 1/4-20 x 1.50, Grade 5

$

$

Not available

4

Cub Cadet 00012158

Washer

$4.49

$

In Stock, Qty 9

0

5

Cub Cadet 712-04065

Nylock Insert Lock Nut, 3/8-16

$3.99

$

In Stock, Qty 20+

0

6

Cub Cadet 00013116

Hex Cap Screw, 5/16-18 x 1-1/4

$5.99

$

In Stock, only 1 left!

0

7

Cub Cadet 00022560

Hex Nut, Flange Lock, 3/8-16
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

8

Cub Cadet 941-0598

Hex Flange Bearing, .752 ID

$12.99

$

In Stock, Qty 20+

0

9

Cub Cadet 712-3004A

Nut, Lock, HexFlange, 5/16-18

$3.99

$

In Stock, Qty 20+

0

10

Cub Cadet 736-0262

Flat Washer, .385 ID x .870 OD x .092

$3.99

$

Usually ships in 3-6 days

0

11

Cub Cadet 01001714

Control Sleeve, Drive Black

$11.99

$

Usually ships in 3-6 days

0

12

Cub Cadet 01001928

Carriage Bolt, 3/8-16, 2.50

$

$

Not available

13

Cub Cadet 912-3027

Nut, 1/4-20, Hex Flange Lock

$4.49

$

In Stock, Qty 20+

0

14

Cub Cadet 914-0104

Cotter Pin, .072 x 1.12 Lg
(Superseded to 714-0104)

$4.49

$

In Stock, Qty 20+

0

15

Cub Cadet 01003574

Neutral Brake Spring

$10.99

$

Usually ships in 3-6 days

0

16

Cub Cadet 01008600

Socket Head Capscrew, 5/16-18 x 1.50
(Superseded to 710-3250)

$4.99

$

Usually ships in 3-6 days

0

17

Cub Cadet 01009219

Pivot Brake Joint

$

$

Not available

18

Cub Cadet 01009253

Washer, 5/16-18
(Superseded to 936-0227)

$

$

Not available

19

Cub Cadet 02001335

Compression Spring, .58 OD x 1.45LG

$

$

Not available

19

Cub Cadet 01009333

Spacer, .625 OD x .390 ID x 1.2
(Superseded to 732-3065)

$3.99

$

In Stock, only 1 left!

0

20

Cub Cadet 738-0372B

Spacer, 1.0 x .38 x .38

$9.49

$

In Stock, Qty 20+

0

21

Cub Cadet 02000283P

Input Brake Arm Assembly

$

$

Not available

22

Cub Cadet 02000285P

Output Brake Arm Assembly

$

$

Not available

23

Cub Cadet 02000286

Pivot Brake Shaft

$

$

Not available

24

Cub Cadet 02000287

Steering Brake Rod

$

$

Not available

25

Cub Cadet 02000622

Spacer, .380 x .563 x .405 Lg.

$

$

Not available

26

Cub Cadet 02000623

Steering Lock Rod

$

$

Not available

27

Cub Cadet 02000628

Brake Handle Mounting Plate

$

$

Not available

28

Cub Cadet 02000633

Brake Handle Assembly

$

$

Not available

29

Cub Cadet 02000634

Brake Link Rod

$

$

Not available

30

Cub Cadet 02000697

Spacer, .259 x .375 x .707 Lg.

$

$

Not available

31

Cub Cadet 710-3005

Hex Cap Screw, 3/8 -16 x 1.25

$3.99

$

In Stock, Qty 11

0

32

Cub Cadet 00011211

Grip, Neutral Latch

$8.99

$

In Stock, only 2 left!

0

32

Cub Cadet 01001714

Control Sleeve, Drive Black

$11.99

$

Usually ships in 3-6 days

0
