Z-Force 60 (53AA5DBJ709) - Cub Cadet 60" Z-Force Zero-Turn Mower, Kawasaki Kawasaki Engine Assembly 23HP Parts Diagram

60" Z-Force Zero-Turn Mower, Kawasaki

Kawasaki Engine Assembly 23HP Parts Diagram

  • Title

1

Cub Cadet 00005763

Hex Nut, 7/16-14
(Superseded to 912-3019)

$6.99

$

In Stock, only 1 left!

0

2

Cub Cadet 00006129

HHCS, 5/16-18, 1-3/4

$6.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 00008495

Capscrew, 3/8-16 x 1-3/4

$6.99

$

In Stock, Qty 8

0

4

Cub Cadet 00025344

Key, 1/4 x .875

$

$

Not available

5

Cub Cadet 00012158

Washer

$4.49

$

In Stock, Qty 9

0

6

Cub Cadet 00013116

Hex Cap Screw, 5/16-18 x 1.25

$5.99

$

In Stock, only 1 left!

0

7

Cub Cadet 00014602

Round Hd. Machine Screw, 10-32 x 3/4

$

$

Not available

8

Cub Cadet 00014608

Lock Nut, Nylon Insert, 10-32
(Superseded to 712-05003)

$3.49

$

In Stock, only 3 left!

0

9

Cub Cadet 00020508

Carriage Bolt, 5/16-18 x .75

$6.99

$

In Stock, only 3 left!

0

10

Cub Cadet 00022560

Flange Lock, Hex Nut, 3/8-16
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

11

Cub Cadet 00030782

Idler Pulley w/ Adaptor
(Superseded to 02004558)

$22.99

$

In Stock, only 2 left!

0

12

Cub Cadet 00060056

Nut Washer, W/Star, 8-32

$6.99

$

In Stock, only 1 left!

0

13

Cub Cadet 00060078

Grease Fitting, 1/4-28 x 3/16
(Superseded to 737-04345)

$4.99

$

In Stock, Qty 6

0

14

Cub Cadet 01000199

Extension Spring, 1.0 OD x 5.00

$17.99

$

In Stock, only 4 left!

0

15

Cub Cadet 01000302

Shoulder Screw, 7/16-14
(Superseded to 738-3102)

$21.99

$

In Stock, only 1 left!

0

16

Cub Cadet 01000364

Hex Carriage Screw, 3/8-16, 1.75
(Superseded to 710-0560)

$6.99

$

In Stock, Qty 11

0

17

Cub Cadet 01000389

Lock Washer, 7/16
(Superseded to 936-0171)

$4.49

$

In Stock, only 4 left!

0

18

Cub Cadet 01005314

Washer, 7/16 ID x 1.75 OD x .25
(Superseded to 736-04131)

$15.99

$

In Stock, only 1 left!

0

19

Cub Cadet 01000635

Hexflange Lock Nut, 5/16-18
(Superseded to 712-3004A)

$3.99

$

In Stock, Qty 20+

0

20

Cub Cadet 01000721

Machine Screw, 8-32, .375
(Superseded to 710-3217)

$6.99

$

In Stock, Qty 7

0

21

Cub Cadet 01000728

Clip, Heat Shield Cable
(Superseded to 726-04124)

$3.99

$

Usually ships in 3-6 days

0

22

Cub Cadet 01000811

Tube Clamp, 1.375
(Superseded to 710-0148)

$4.49

$

In Stock, Qty 16

0

23

Cub Cadet 01000813

Hex Cap Screw, 7/16-20 x 3.0
(Superseded to 710-0510)

$11.99

$

In Stock, only 1 left!

0

24

Cub Cadet 01000981

Hex Cap Screw, 1.25 x 20mm

$

$

Not available

25

Cub Cadet 01002601

Hex Cap Screw, 3/8-16, .750
(Superseded to 710-0216)

$4.49

$

In Stock, Qty 15

0

26

Cub Cadet 02002160

Electric Clutch
(Superseded to 02002160P)

$

$

Not available

27

Cub Cadet 01003271

Choke Control Cable, 43.0
(Superseded to 01003271P)

$

$

Not available

28

Cub Cadet 01003283

Oil Drain Hose

$84.99

$

Usually ships in 3-6 days

0

28

Cub Cadet 737-0103

Oil Drain Plug
(Superseded to 737-04202)

Note: not shown

$6.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 01004004

Control Throttle Knob
(Superseded to 731-04914)

$13.99

$

Usually ships in 3-6 days

0

30

Cub Cadet 01005314

Flat Washer, 7/16 IDx 1.750 OD x .250T
(Superseded to 736-04131)

$15.99

$

In Stock, only 1 left!

0

31

Cub Cadet 01007340

Pulley, Cast, 1.125" Bore

$

$

Not available

32

Cub Cadet 01008349

V-Belt, 56.00
(Superseded to 01008349P)

$31.99

$

In Stock, Qty 13

0

33

Cub Cadet 01008404

Spacer, .635 ID x .28

$15.99

$

In Stock, only 1 left!

0

34

Cub Cadet 01008623

Muffler Accessory Exhaust Tube

$

$

Not available

35

Cub Cadet 01009253

Washer, 5/16-18
(Superseded to 936-0227)

$

$

Not available

36

Cub Cadet 01009299

Muffler Accessory, Kawasaki
(Superseded to 01009299P)

$

$

Not available

37

Cub Cadet 01009591

Spacer, 1.75 OD x 1.135 ID x 1.125

$31.99

$

Usually ships in 3-6 days

0

38

Cub Cadet 02000645

Throttle, Control Cable, 39.0

$45.99

$

In Stock, only 2 left!

0

39

Cub Cadet 02001545

Neutral Lock Mounting Bracket

$

$

Not available

40

Cub Cadet 02001596

Engine Idler Arm Assembly Includes:

$173.99

$

Usually ships in 3-6 days

0

40

Cub Cadet 01000308

Bearing
(Superseded to 741-04555)

$16.99

$

In Stock, Qty 18

0

41

Hose, 1/4" Dia

Note: purchase locally

$

$

Not available

42

Cub Cadet 02001994

Retainer Clutch Assembly, Ogura
(Superseded to 02001992-0637)

$30.99

$

Usually ships in 3-6 days

0

43

Cub Cadet 02001993

23HP Kawasaki Engine use 10W40 oil
(Superseded to 02001993P)

$

$

Not available

44

Cub Cadet 02002158

Engine Spacer

$23.99

$

Usually ships in 3-6 days

0
