Z-Force 44 (53AA5B6L710) - Cub Cadet 44" Z-Force Zero-Turn Mower, Kohler Control Assembly (2005) Parts Diagram

44" Z-Force Zero-Turn Mower, Kohler

Control Assembly (2005) Parts Diagram

  • Title

1

Cub Cadet 00012382

Hex Cap Screw, 5/16-18 x 1-1/2

$

$

Not available

2

Cub Cadet 00083192

Idler Washer
(Superseded to 736-0258)

$4.49

$

Usually ships in 3-6 days

0

3

Cub Cadet 00008495

Capscrew, 3/8-16 x 1-3/4

$6.99

$

In Stock, Qty 8

0

4

Cub Cadet 01000372

Carriage Bolt, 3/8-16
(Superseded to 710-3178)

$4.49

$

In Stock, Qty 20+

0

5

Cub Cadet 00012165

Nylock Nut, 5/16-18

$4.99

$

In Stock, only 1 left!

0

6

Cub Cadet 01008620

Self Tapping Screw, 5/16-18 x 3/4
(Superseded to 710-04484)

$3.99

$

In Stock, Qty 20+

0

7

Cub Cadet 01000629

Self Tapping Screw, 1/4-20 x .75
(Superseded to 710-0642)

$4.49

$

In Stock, Qty 20+

0

8

Cub Cadet 00013595

Parking Brake Grip

$9.99

$

Usually ships in 3-6 days

0

9

Cub Cadet 00021797

Spring, .85 OD x 1 Lg

$9.49

$

Usually ships in 3-6 days

0

10

Cub Cadet 00022560

Hex Nut, 3/8-16 Flange Lock
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

11

Cub Cadet 00070022

Flat Washer, 1.25 x .411 x .100

$

$

Not available

12

Cub Cadet 01000628

Screw, 1/4-20 x 1/2
(Superseded to 710-0599)

$4.49

$

In Stock, Qty 20+

0

13

Cub Cadet 01000635

Hex Nut, 5/16-18 Flange Lock
(Superseded to 712-3004A)

$3.99

$

In Stock, Qty 20+

0

14

Kit, Armrest (Available through Whole goods)

$

$

Not available

15

Cub Cadet 01002634

Shoulder Screw, 3/8-16, .5 x 2.345

$25.99

$

Usually ships in 3-6 days

0

16

Cub Cadet 01002753

Groment, 2.5 OD x 1.0 Lg
(Superseded to 735-04286)

$8.99

$

In Stock, Qty 14

0

17

Cub Cadet 01002766

Hex Nut, 1/4-20 Flange Lock
(Superseded to 912-3027)

$4.49

$

In Stock, Qty 17

0

18

Cub Cadet 01002772

Spacer, .375 x .50 x 1.02
(Superseded to 750-0434)

$6.99

$

Usually ships in 3-6 days

0

19

Cub Cadet 01003563

U-Nut, 5/16-18
(Superseded to 926-0211)

$4.49

$

In Stock, only 1 left!

0

20

Cub Cadet 02000614

Foot Rest Bracket

$

$

Not available

21

Cub Cadet 01008198

Left Hand Brake Cable
(Superseded to 01008198P)

Note: (not shown)

$42.99

$

In Stock, only 4 left!

0

22

Cub Cadet 01008199

Right Hand Brake Cable
(Superseded to 01008199P)

Note: (not shown)

$

$

Not available

23

Cub Cadet 01008482

Control Housing Weldment

$

$

Not available

24

Cub Cadet 01008413

Seat Adjust
(Superseded to 02001942)

$

$

Not available

25

Cub Cadet 01010006

Left Hand Control Console
(Superseded to 02001307)

$

$

Not available

26

Cub Cadet 01010007

Right Hand Control Console
(Superseded to 02001308)

$

$

Not available

27

Cub Cadet 02000630

Parking Brake Lever

$

$

Not available

28

Cub Cadet 01008488

Brake Cable Bracket

$10.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 01008491

Front Tank Mounting Bracket

$

$

Not available

30

Cub Cadet 01008528

Lapbar Stop Bracket

$

$

Not available

31

Cub Cadet 01008539

U-Nut, 1/4-20
(Superseded to 726-3054)

$4.99

$

Usually ships in 3-6 days

0

32

Cub Cadet 01008572

Battery Edge Trim
(Superseded to 735-04130)

$8.49

$

Usually ships in 3-6 days

0

33

Cub Cadet 01008583

Seat Mounting Bracket

$

$

Not available

34

Cub Cadet 00012166

Hex Nut, 5/16-18

$

$

Not available

35

Cub Cadet 01000960

Washer, .325 x .930 x .045
(Superseded to 936-0425)

$

$

Not available

36

Cub Cadet 01006528

Abrasive Foot Pad

$

$

Not available

37

Cub Cadet 01000723

Flat Washer, .406 ID x 1.0 OD x .105
(Superseded to 736-3052)

$4.49

$

In Stock, Qty 20+

0
