Z 5200 (CMXGNAM211701) (17ARFACS093) - Craftsman 42" Zero-Turn Mower (2022) .Quick Reference Parts Diagram

42" Zero-Turn Mower

.Quick Reference Parts Diagram

  • Title

MTD KH-32-883-09-S1

FLTR KIT-AIR/PRECL
(Superseded to 490-200-K054)

Note: Air Filter & Pre-Cleaner

$39.99

$

In Stock, Qty 20+

0

MTD KH-25-050-22-S1

FUEL FILTER

Note: Fuel Filter

$9.99

$

Usually ships in 2-5 days

0

MTD KH-12-050-01-S

OIL FILTER-SHORT (BOXED)

Note: Oil Filter

$13.99

$

In Stock, Qty 20+

0

MTD KH-32-083-10-S

PRECLNR-FOAM (LPAC

Note: Pre-Filter

$6.99

$

In Stock, Qty 20+

0

MTD KH-25-132-23-S

SPARK PLUG

Note: Spark Plug

$7.49

$

In Stock, Qty 12

0

MTD 754P06134

V-BELT A SEC x 117.0

Note: Belt (PTO / Deck)

$56.99

$

In Stock, Qty 20+

0

MTD 490-501-Y081

Troy-Bilt 42" RZT DECK BELT

Note: Retail Packaged Part

$

$

Currently unavailable

MTD 954-04317A

TRANSMISSION DRIVE BELT A x 67

Note: Belt (Trans Drive)

$50.99

$

In Stock, only 2 left!

0

MTD 742P05528

21.23" BLADE (2IN1) (S SHAPE CENTER HOLE)

Note: Blades

$24.99

$

In Stock, Qty 20+

0

MTD 746P05631

PARK BRAKE CABLE

Note: Cable (Park Brake)

$33.99

$

Usually ships in 3-6 days

0

MTD 746P06891

THROTTLE CABLE 51.0LG

Note: Cable (Throttle)

$45.99

$

In Stock, Qty 20+

0

MTD 925-1745A

IGNITION KEY

Note: Ignition Keys

$17.99

$

In Stock, Qty 20+

0

MTD 618P09260

SPINDLE ASSEMBLY (6.3 DIA)

Note: Spindle Assembly

$132.99

$

In Stock, Qty 20+

0

MTD 734-06305A

DECK WHEEL (5.0 DIA x 1.875)

Note: Wheels (Front Deck)

$15.99

$

In Stock, Qty 16

0

MTD 951-12179C

FUEL CAP W/TETHER

Note: Fuel Cap

$38.99

$

In Stock, only 2 left!

0

MTD 490-000-M034

OIL SAE 30 48OZ BOTTLE

Note: Oil

$15.99

$

In Stock, only 2 left!

0

MTD 490-241-0023

CHAINS 20"X8"

$87.99

$

In Stock, only 2 left!

0

MTD 757-06093

ARM REST KIT (06027/06100)

$199.99

$

Usually ships in 3-6 days

0
