XT2-LX 42 KW (13BGA1CS010) - Cub Cadet 42" XT2 Enduro Lawn Tractor, Kawasaki (2016) Fender Parts Diagram

42" XT2 Enduro Lawn Tractor, Kawasaki

Fender Parts Diagram

  • Title

1

Cub Cadet 631-05258

UPPER FENDER COVER (RH)
(Superseded to 631-05258A)

$58.99

$

In Stock, only 1 left!

0

2

Cub Cadet 710-04666

SCREW 1/4-20 x .75 GR5

$6.99

$

In Stock, only 3 left!

0

3

Cub Cadet 710-06133

SCREW M6-1 x .625

$3.99

$

In Stock, Qty 8

0

4

Cub Cadet 710-06147

SCREW 1/4-10 x .750

$3.99

$

In Stock, Qty 20+

0

5

Cub Cadet 710-06335

HEX SCREW WASH TT 3/8-16 x .875

$4.99

$

Usually ships in 3-6 days

0

6

Cub Cadet 712-04064

FLANGE LOCK NUT

$3.99

$

In Stock, Qty 20+

0

7

Cub Cadet 731-09768

FENDER COVER (LH)

$55.99

$

In Stock, Qty 8

0

8

Cub Cadet 731-10354

FENDER COVER (LH)

$23.99

$

In Stock, only 1 left!

0

9

Cub Cadet 731-10434

HANDLE COVER (LH)

$18.99

$

Usually ships in 3-6 days

0

10

Cub Cadet 731-10523

FENDER COVER (RH)

$23.99

$

In Stock, only 1 left!

0

11

Cub Cadet 731-10524

HANDLE COVER (RH)

$18.99

$

In Stock, only 1 left!

0

12

Cub Cadet 732-05182A

COMPRESSION SPRING 2.18 x 3.65 x .207

$11.99

$

In Stock, only 1 left!

0

13

Cub Cadet 783-08279B-4021

REAR FENDER
(Superseded to 783-08279C-4021)

$420.99

$

Usually ships in 3-6 days

0

14

Cub Cadet 783-08559

LIFT INDEX BRACKET

Variations

Cub Cadet 783-08559-0637

Lift Index Bracket - POWDER BLACK (0637)

$18.99

$

Usually ships in 3-6 days

0

$18.99

$

Usually ships in 3-6 days

0
