W (990389) - Simplicity Two-Wheeled Tractor Transmission Group (3643I04) Parts Diagram

Two-Wheeled Tractor

Transmission Group (3643I04) Parts Diagram

  • Title

A

Simplicity 155045

CASE, Gear, Complete w/Bearings & Dowel Pins

$

$

Not available

B

Simplicity 154538

PIN, Roll

$

$

Not available

C

Simplicity 2723007

PIN, Roll

$

$

Not available

D

Simplicity 2154257SM

BEARING, Needle

$27.99

$

In Stock, only 1 left!

0

E

Simplicity 2154258SM

BEARING, Needle

$26.99

$

In Stock, Qty 8

0

F

Simplicity 154259

BEARING, Needle

$

$

Not available

G

Simplicity 2154260SM

BEARING, Axle Tube

$117.99

$

Usually ships in 2-12 days

0

H

Simplicity 154066

ROD, Shift

$

$

Not available

J

Simplicity 2154261

STEM, Shift

$

$

Not available

K

Simplicity 717010

NUT, Hex, Full, 3/8"-24 NF

$

$

Not available

L

Simplicity 154067

SHAFT, Shifter, Rev. Med.

$

$

Not available

M

Simplicity 154068

SHAFT, Shifter, High, Low

$

$

Not available

N

Simplicity 1729260SM

RING, Retaining

$5.99

$

Usually ships in 2-12 days

0

P

Simplicity 715019

SETSCREW, Hollow Head, Cone Point, 5/16"-18 NC x 1/2" LG
(Superseded to 715455)

$14.99

$

Usually ships in 2-12 days

0

Q

Simplicity 2154069SM

FORK, Shift

$227.99

$

Usually ships in 2-12 days

0

R

Simplicity 2154323SM

SPRING

$30.99

$

Usually ships in 2-12 days

0

S

Simplicity 2154262

BALL, Shift Lock

$

$

Not available

T

Simplicity 154070

SHAFT, Pulley

$

$

Not available

U

Simplicity 1612093SM

SEAL, Oil

$10.99

$

In Stock, Qty 20+

0

V

Simplicity 154462

WASHER

$

$

Not available

W

Simplicity 154462

WASHER

$

$

Not available

X

Simplicity 2154264SM

RING, Retaining

$5.99

$

Usually ships in 2-12 days

0

Y

Simplicity 2154264SM

RING, Retaining

$5.99

$

Usually ships in 2-12 days

0

Z

Simplicity 2154354SM

KEY

$15.99

$

Usually ships in 2-12 days

0

AA

Simplicity 2154072

PINION ASSEMBLY, Rev., II

$

$

Not available

AB

Simplicity 2154075

PINION ASSEMBLY, Rev., I & III

$

$

Not available

AC

Simplicity 155014

SHAFT, 1st Intermediate

$

$

Not available

AD

Simplicity 2721503

WASHER, Lock, 3/8" Internal Shakeproof

$

$

Not available

AE

Simplicity 154078

GEAR, Driven, I

$

$

Not available

AF

Simplicity 2154354SM

KEY

$15.99

$

Usually ships in 2-12 days

0

AG

Simplicity 154079

PINION, 1st Intermediate

$

$

Not available

AH

Simplicity 2154080SM

PINION, Driven, III

$96.99

$

Usually ships in 2-12 days

0

AJ

Simplicity 1729259SM

SPACER, Transmission Gear

$5.99

$

In Stock, Qty 7

0

AK

Simplicity 154081

GEAR, Driven, II

$

$

Not available

AL

Simplicity 154082

SPACER

$

$

Not available

AM

Simplicity 2154264SM

RING, Retaining

$5.99

$

Usually ships in 2-12 days

0

AN

Simplicity 2154083

PINION, Reverse

$

$

Not available

AP

Simplicity 2154087SM

GEAR, Reverse

$70.99

$

Usually ships in 2-12 days

0

AQ

Simplicity 154084

SPACER, Reverse Gear

$

$

Not available

AR

Simplicity 2717516

NUT, Lock, 1/2"-20 NF

$

$

Not available

AS

Simplicity 2154325

WASHER

$

$

Not available

AT

Simplicity 2154267SM

KEY

$

$

Not available

AU

Simplicity 2154038SM

WASHER

$5.49

$

Usually ships in 2-12 days

0

AV

Simplicity 2154038SM

WASHER

$5.49

$

Usually ships in 2-12 days

0

AW

Simplicity 2154038SM

WASHER

$5.49

$

Usually ships in 2-12 days

0

AX

Simplicity 154266

RING, Retaining

$

$

Not available

AY

Simplicity 154088

PINION, 2nd Intermediate

$

$

Not available

AZ

Simplicity 154086

SHAFT, 2nd. Intermediate

$

$

Not available

BA

Simplicity 154089

GEAR, 2nd Intermediate

$

$

Not available

BB

Simplicity 154090

SPACER

$

$

Not available

BC

Simplicity 154091

SHAFT, 3rd Intermediate

$

$

Not available

BD

Simplicity 2154038SM

WASHER

$5.49

$

Usually ships in 2-12 days

0

BE

Simplicity 2154038SM

WASHER

$5.49

$

Usually ships in 2-12 days

0

BF

Simplicity 154266

RING, Retaining

$

$

Not available

BG

Simplicity 2154092SM

PINION, 3rd Intermediate

$

$

Not available

BH

Simplicity 154093

GEAR, 3rd Intermediate

$

$

Not available

BJ

Simplicity 2725002

KEY, Woodruff

$

$

Not available

BK

Simplicity 2157188

TUBE, Axle

$

$

Not available

BL

Simplicity 2727002

FITTING, Grease

$

$

Not available

BM

Simplicity 154095

GEAR, Drive

$

$

Not available

BN

Simplicity 2157120SM

KEY

$6.99

$

In Stock, only 1 left!

0

BP

Simplicity 2154097SM

WASHER

$

$

Not available

BQ

Simplicity 2154097SM

WASHER

$

$

Not available

BR

Simplicity 2154268SM

RING, Snap

$7.49

$

In Stock, only 3 left!

0

BS

Simplicity 2154268SM

RING, Snap

$7.49

$

In Stock, only 3 left!

0

BT

Simplicity 2154130SM

WASHER, Axle Tube

$6.49

$

Usually ships in 2-12 days

0

BU

Simplicity 2154130SM

WASHER, Axle Tube

$6.49

$

Usually ships in 2-12 days

0

BV

Simplicity 2153068SM

BEARING

$31.99

$

Usually ships in 2-12 days

0

BW

Simplicity 2153068SM

BEARING

$31.99

$

Usually ships in 2-12 days

0

BX

Simplicity 2154269SM

SEAL

$

$

Not available

BY

Simplicity 2154269SM

SEAL

$

$

Not available

BZ

Simplicity 2705011

CAPSCREW, Hex, 3/8"-16 x 5/8" LG

$

$

Not available

CA

Simplicity 2154270

GASKET, Gear Case

$

$

Not available

CB

Simplicity 154098

SPACER, Axle Tube

$

$

Not available

CC

Simplicity 155046

COVER, Gear Case, Complete w/bearings
(Superseded to 709102)

$26.99

$

Usually ships in 2-12 days

0

CD

Simplicity 154537

PIN, Roll

$

$

Not available

CE

Simplicity 2154257SM

BEARING, Needle

$27.99

$

In Stock, only 1 left!

0

CF

Simplicity 2154257SM

BEARING, Needle

$27.99

$

In Stock, only 1 left!

0

CG

Simplicity 2154271SM

BEARING, Needle

$

$

Not available

CH

Simplicity 154259

BEARING, Needle

$

$

Not available

CJ

Simplicity 2154260SM

BEARING, Axle Tube

$117.99

$

Usually ships in 2-12 days

0

CK

Simplicity 2726003

PLUG, Pipe, 3/8"

$

$

Not available

CM

Simplicity 2705007

CAPSCREW, Hex, 5/16"-18 NC x 1" LG

$

$

Not available

CN

Simplicity 2720001

WASHER, Lock, 5/16"

$

$

Not available

CP

Simplicity 154352

PIN ASSEMBLY, Rev. Gear

$

$

Not available

CQ

Simplicity 2726003

PLUG, Pipe, 3/8"

$

$

Not available
