UVG 1621 BV (7085632) - Simplicity Turf Cruiser Utility Vehicle with Generator, 16hp Briggs & Stratton Brake Assembly (179braa) Parts Diagram

Turf Cruiser Utility Vehicle with Generator, 16hp Briggs & Stratton

Brake Assembly (179braa) Parts Diagram

  • Title

1

Simplicity 7058683

BRAKE SHAFT ASSEMBLY, Rear CVT
(Superseded to 7058683YP)

$353.99

$

Usually ships in 2-12 days

0

2

Simplicity 7072986

SPRING, CVT Brake

$

$

Not available

3

Simplicity 7073015

BRAKE SWIVEL, w/.531 Thru Hole
(Superseded to 7073015YP)

$15.99

$

Usually ships in 2-12 days

0

4

Simplicity 7091299SM

NUT, Hex Nyloc, 3/8-16
(Superseded to 703117)

$3.49

$

In Stock, Qty 20+

0

5

Simplicity 7073116

BRACKET, Swivel Retainer, Used on Model 85668
(Superseded to 7073116YP)

$15.99

$

Usually ships in 2-12 days

0

5

Simplicity 7063361

BRACKET, Swivel Retainer, Used on Model 85632 & 85903

$

$

Not available

6

Simplicity 1921973SM

CAPSCREW, Hex Head, 3/8-16 x 3-1/4 GR 5

$5.49

$

Usually ships in 2-12 days

0

7

Simplicity 7091293

SCREW, Hex Washer Self-Tap, 1/4-20 x 3/8
(Superseded to 703583)

$4.99

$

In Stock, Qty 20+

0

8

Simplicity 7072645

BEARING, 1 I.D.
(Superseded to 7072645YP)

$6.49

$

Usually ships in 2-12 days

0

9

Simplicity 2827320SM

RING, 1.00 Dia. External Retaining

$8.49

$

Usually ships in 2-12 days

0

10

Simplicity 7016561

BUSHING, 14 Ga Machine
(Superseded to 7016561YP)

$5.49

$

In Stock, Qty 8

0

11

Simplicity 7079295

NUT, Hex Nyloc, 1/2-20
(Superseded to 7079295YP)

$3.49

$

Usually ships in 2-12 days

0

12

Simplicity 7091508SM

CARRIAGE BOLT, 5/16-18 x 3/4 GR 5
(Superseded to 703185)

$3.49

$

In Stock, Qty 20+

0

13

Simplicity 1931277SM

NUT, Hex Flange Lock, 5/16-18 GR 5
(Superseded to 703409)

$5.49

$

In Stock, Qty 20+

0

14

Simplicity 7027230SM

CAPSCREW, Hex Head, 1/4-20 x 1 GR 5
(Superseded to 703820)

$3.99

$

In Stock, only 4 left!

0

15

Simplicity 7091603SM

NUT, Hex Nyloc, 1/4-20
(Superseded to 703232)

$4.49

$

In Stock, Qty 20+

0

16

Simplicity 7073097

PAWL, Park Brake
(Superseded to 7073097YP)

$7.99

$

Usually ships in 2-12 days

0

17

Simplicity 7073098

BRACKET, LH Park Brake Pawl Pivot, Used on Model 85668
(Superseded to 7073098YP)

$20.99

$

Usually ships in 2-12 days

0

17

Simplicity 7063362

BRACKET, LH Park Brake Pawl Pivot, Used on Model 85632 & 85903

$

$

Not available

18

Simplicity 7073099

BRACKET, RH Park Brake Pawl Pivot, Used on Model 85668

$

$

Not available

18

Simplicity 7063363

BRACKET, RH Park Brake Pawl Pivot, Used on Model 85632 & 85903

$

$

Not available

19

Simplicity 7073100SM

SPACER, Park Brake

$9.99

$

Usually ships in 2-12 days

0

20

Simplicity 7072550

SPRING, Pawl Return
(Superseded to 7011224YP)

$18.99

$

Usually ships in 2-12 days

0

21

Simplicity 7090299

SCREW, Hex Washer Self-Tap, #10-32 x 1
(Superseded to 7090299YP)

$4.49

$

Usually ships in 2-12 days

0

22

Simplicity 7091801

NUT, Hex Center Lock, #10-32
(Superseded to 7091801YP)

$2.99

$

Usually ships in 2-12 days

0

23

Simplicity 7073013

PIN, Brake Anchor
(Superseded to 7073013YP)

$17.99

$

Usually ships in 2-12 days

0

24

Simplicity 7071953

RETAINING RING, 5/8 Shaft
(Superseded to 7071953YP)

$2.99

$

Usually ships in 2-12 days

0

25

Simplicity 7090559

NUT, Hex Jam, 1/2-20 GR 5 or B
(Superseded to 703903)

$3.49

$

In Stock, Qty 20+

0

26

Simplicity 7072985

BRAKE ROD, Rear CVT
(Superseded to 7072985YP)

$47.99

$

Usually ships in 2-12 days

0

27

Simplicity 7027941SM

CABLE, Parking Brake

$

$

Not available

28

Simplicity 7072989

ROD, Lower CVT Brake, 1/2-20 Thread, Both Ends
(Superseded to 7072989YP)

$47.99

$

Usually ships in 2-12 days

0

29

Simplicity 7058751

BRAKE ASSEMBLY, Utility Vehicle (Includes Ref. Nos. 1 thru 7), Used on Model 85668

$

$

Not available

29

Simplicity 7063360

BRAKE ASSEMBLY, Utility Vehicle (Includes Ref. Nos. 1 thru 7), Used on Model 85632 & 85903

$

$

Not available
