UT-20725 - Homelite String Trimmer, 25cc Muffler - Air Cleaner Parts Diagram

String Trimmer, 25cc

Muffler - Air Cleaner Parts Diagram

  • Title
1

Homelite A07142A

MUFFLER ASSEMBLY
(Superseded to PA01073)

Note: (Incl. items 2 - 5)

$35.99

$

Usually ships in 3-7 days

0

2

Homelite 82600

SCREW, Taptite - (8-32 X 3/8")

Note: (Torque Specs 25-35 In/Lbs [2.8-4.0 Nm])

$1.49

$

Usually ships in 3-7 days

0

3

Homelite 06502

SCREEN-Spark

$

$

Not available

4

Homelite 09343

GASKET-Muffler

$

$

Not available

5

Homelite 88083

SCREW, Truss Hd. - (10-24 X 2.188)
(Superseded to PS03999)

Note: (Torque Specs 50-60 In/Lbs [5.6-6.8 Nm])

$

$

Not available

6

Homelite UP00022

Air Filter Kit
(Superseded to 983930001)

Note: (Incl. items 7 & 8)

$

$

Not available

7

Homelite D98760B

Filter-Air
(Superseded to 98760)

$

$

Not available

8

Homelite 81208

NUT-Hex (10-24)

Note: (Torque Specs 30-40 In/Lbs [3.4-4.5 Nm])

$

$

Not available
