TLBC35201BVG (3800029) - Giant-Vac Trailer Mount Truck Loader Vacuum Chipper, 35hp Engine Group Parts Diagram

Trailer Mount Truck Loader Vacuum Chipper, 35hp

Engine Group Parts Diagram

  • Title

1

3010196

Engine Base

$

$

Not available

2

613477-0135-E1

* Engine, 35hp Briggs & Stratton Vanguard

$

$

Not available

--

3039265

Muffler, Exhaust Assy (Not Shown)

$

$

Not available

3

Giant-Vac 3031747

Bolt, Hex 3/8 x 2 (Motor Mount Bolt)

$

$

Currently unavailable

3

Giant-Vac 3031595

Bolt, Hex 3/8 x 1-3/4 (Motor Mount Bolt)
(Superseded to 704289)

$4.99

$

In Stock, Qty 13

0

4

Giant-Vac 3031008

Washer, Lock 3/8
(Superseded to 703454)

$3.49

$

In Stock, Qty 17

0

5

Giant-Vac 3031009

Nut, Hex 3/8
(Superseded to 7091302SM)

$4.49

$

Usually ships in 2-12 days

0

7

Giant-Vac 3031447

5/8-18 x 2" Impeller Bolt & Key Group

$

$

Currently unavailable

8

3040117

Fuel Tank, 6 Gal.

$

$

Not available

9

3040119

Fuel Tank Cap

$

$

Not available

10

Giant-Vac 3031755

Hose, Rubber Fuel 1/4" x 10" Length

$

$

Not available

11

3031445

Inline Fuel Shutoff Valve

$

$

Not available

12

Giant-Vac 3031642

Battery Cable - 32SS (Positive)

$

$

Currently unavailable

13

Giant-Vac 3031643

Battery Cable - 16SS (Ground)

$

$

Currently unavailable

14

Giant-Vac 3039020

Battery

$

$

Currently unavailable

15

Giant-Vac 3040118

Battery Box

$

$

Currently unavailable

16

3031158

Gas Tank Mount

$

$

Not available

17

3031157

Fuel Tank Strap

$

$

Not available

--

Giant-Vac 3034041

Clamp, Hose 1/4 Worm Drive (Not Shown)

$

$

Currently unavailable

--

Giant-Vac 3031836

Battery Terminal Cover - Red (Not Shown)

$

$

Currently unavailable

--

Giant-Vac 3031837

Battery Terminal Cover - Black (Not Shown)

$

$

Currently unavailable
