TBSS (41AJSS-C966) - Troy-Bilt String Trimmer Attachment General Assembly Parts Diagram

String Trimmer Attachment

General Assembly Parts Diagram

  • Title

1

Troy-Bilt 753-1212

Lower Drive Shaft Housing Assembly
(Superseded to 753-04089)

$49.99

$

Usually ships in 3-6 days

0

2

Troy-Bilt 753-05182

Lower Flexible Drive Shaft

$31.99

$

In Stock, only 1 left!

0

3

Troy-Bilt 791-145569

Anti-Rotation Screw

$9.99

$

In Stock, Qty 7

0

4

Troy-Bilt 791-180547

Shield Mounting Hardware

$

$

Not available

5

MTD 791-180548

Shield and Blade Assembly (includes 6)

$

$

Not available

6

Troy-Bilt 791-682061

Blade Assembly

$14.99

$

In Stock, only 1 left!

0

7

Troy-Bilt 753-05188

Gearbox Assembly (includes 8-20)

$

$

Not available

8

Troy-Bilt 791-181457

Outer Spool Assembly (includes 10)

$39.99

$

In Stock, only 1 left!

0

9

Troy-Bilt 791-181561

Thrust Washer

$4.49

$

In Stock, Qty 5

0

10

Troy-Bilt 791-181458

Retaining Ring

$4.49

$

In Stock, Qty 11

0

11

Troy-Bilt 791-181459

Small Spring

$4.49

$

In Stock, only 2 left!

0

12

Troy-Bilt 753-04257

Slider

$7.49

$

In Stock, Qty 20+

0

13

Troy-Bilt 791-181532

E-Clip

$4.49

$

In Stock, Qty 8

0

14

Troy-Bilt 791-181531

Spring

$4.49

$

In Stock, Qty 9

0

15

Troy-Bilt 791-181462

Plunger

$

$

Not available

16

Troy-Bilt 791-181463

C-Clip

$3.99

$

Usually ships in 3-6 days

0

17

Troy-Bilt 791-181464

Inner Reel
(Superseded to 791-181460B)

$32.99

$

Usually ships in 3-6 days

0

18

Troy-Bilt 791-181465B

Large Spring

$10.99

$

In Stock, only 1 left!

0

19

Troy-Bilt 791-181467

Foam Seal

$

$

Not available

20

Troy-Bilt 791-181468B

Bump Head Knob Assembly (includes 18 & 19)

$

$

Not available

Troy-Bilt 791-181472

Replacement Line, .080 Diameter
(Superseded to 791-181460B)

Note: Items Not Shown

$32.99

$

Usually ships in 3-6 days

0

Troy-Bilt 791-181460B

Reel and Line Assembly

Note: Items Not Shown

$32.99

$

Usually ships in 3-6 days

0

Troy-Bilt 791-612605

Hanger Accessory
(Superseded to 731-08926)

Note: Items Not Shown

$2.99

$

In Stock, only 3 left!

0
