TB 4 BP (41CR4BPG966) - Troy-Bilt Backpack Blower General Assembly Parts Diagram

Backpack Blower

General Assembly Parts Diagram

  • Title

1

Troy-Bilt 753-06000

Nozzle

$13.99

$

In Stock, only 1 left!

0

2

Troy-Bilt 753-05971

Lower Blower Tube

$15.99

$

Usually ships in 3-6 days

0

3

Troy-Bilt 753-05975

Throttle Grip Assembly

$53.99

$

In Stock, only 1 left!

0

4

Troy-Bilt 753-05991

Upper Blower Tube

$20.99

$

In Stock, only 1 left!

0

5

Troy-Bilt 726-04080

Clamp

$11.99

$

In Stock, Qty 10

0

6

Troy-Bilt 753-05641

Flex Tube

$31.99

$

Usually ships in 3-6 days

0

7

Troy-Bilt 753-05990

Elbow Tube

$18.99

$

Usually ships in 3-6 days

0

8

Troy-Bilt 753-06345

Grip

$5.49

$

Usually ships in 3-6 days

0

9

Troy-Bilt 753-06141

Support System
(Superseded to 753-05645)

$108.99

$

Usually ships in 3-6 days

0

10

Troy-Bilt 912-0442

Nut
(Superseded to 712-0442)

$

$

Not available

11

Troy-Bilt 791-182678

Washer
(Superseded to 4150)

$3.49

$

Usually ships in 3-6 days

0

12

Troy-Bilt 753-05648

Insulator Mount

$14.99

$

Usually ships in 3-6 days

0

13

Troy-Bilt 753-05786

Intake Cover

$5.99

$

Usually ships in 3-6 days

0

14

Troy-Bilt 710-04194

Screw

$4.49

$

In Stock, Qty 20+

0

15

Troy-Bilt 753-05658

Impeller Housing Assembly

$78.99

$

Usually ships in 3-6 days

0

16

Troy-Bilt 791-180050

Nut
(Superseded to 712-0324)

$3.99

$

In Stock, Qty 16

0

17

Troy-Bilt 791-181003

Screw
(Superseded to 9052-1)

$

$

Not available

18

Troy-Bilt 753-05989

Impeller (includes 19)

$28.99

$

Usually ships in 3-6 days

0

19

Troy-Bilt 791-182409

Washer

$4.99

$

In Stock, Qty 5

0

20

Troy-Bilt 731-06074

Throttle Retaining Clip

$4.49

$

Usually ships in 3-6 days

0

21

Troy-Bilt 753-05289

Fuel Cap

$22.99

$

In Stock, Qty 8

0

22

Troy-Bilt 753-05662

Fuel Tank Assembly (includes 23)

$

$

Not available

23

Troy-Bilt 753-05663

Stand

$18.99

$

In Stock, only 4 left!

0

24

Troy-Bilt 753-05660

Engine Cover Assembly

$34.99

$

In Stock, only 3 left!

0

25

MTD 791-182348

Screw

$

$

Not available

26

Troy-Bilt 753-06340

Hip Belt

$18.99

$

Usually ships in 3-6 days

0
