Tank 60 (53AH8STD050) - Cub Cadet 60" Tank Zero-Turn Mower, 25hp Kohler Lift Assembly Parts Diagram

60" Tank Zero-Turn Mower, 25hp Kohler

Lift Assembly Parts Diagram

  • Title

1

Cub Cadet 00008495

Hex Cap Screw, 3/8-16 x 1-3/4

$6.99

$

In Stock, Qty 8

0

2

Cub Cadet 00012152

Lock Nut w/Nylon Insert

$4.49

$

In Stock, only 1 left!

0

3

Cub Cadet 00013291

Nut, 1/4-20

$2.99

$

In Stock, only 3 left!

0

4

Cub Cadet 00013416

Hex Cap Screw, 1/4-20 x 1.00
(Superseded to 710-0597)

$3.99

$

In Stock, Qty 13

0

5

Cub Cadet 00021956

Hair Pin
(Superseded to 914-04023)

$4.49

$

In Stock, Qty 20+

0

6

Cub Cadet 00022560

Hex Nut, Flange Lock, 3/8-16
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

7

Cub Cadet 00031672

Cap Screw, 1/4-20 x 1-1/2

$3.49

$

Usually ships in 3-6 days

0

8

Cub Cadet 00083192

Idler Washer
(Superseded to 736-0258)

$4.49

$

In Stock, only 4 left!

0

9

Cub Cadet 736-3052

Flat Washer, .406 ID x 1.0 OD x .105

$4.49

$

In Stock, Qty 20+

0

10

Cub Cadet 01001744

Eye Bolt, 5/8ID
(Superseded to 710-05355)

$17.99

$

In Stock, only 2 left!

0

11

Cub Cadet 01001746-0637

Eye Bolt Mount Link, 5/8 ID

$34.99

$

In Stock, only 1 left!

0

12

Cub Cadet 01002011

Hex Carriage Screw, 3/8-16, 2.00

$

$

Not available

13

Cub Cadet 912-3027

Hex Flange Lock Nut, 1/4-20

$4.49

$

In Stock, Qty 20+

0

14

Cub Cadet 750-0434

Spacer, .375 ID x .50 OD x 1.02

$6.99

$

Usually ships in 3-6 days

0

15

Cub Cadet 01003535

Shoulder Screw, 0.625 OD x .437 Lg.

$28.99

$

In Stock, only 2 left!

0

16

Cub Cadet 01003993

Linch Pin, 3/16 Dia.
(Superseded to 753-04070)

$9.99

$

In Stock, Qty 20+

0

17

Cub Cadet 01004003

Nylon Flat Washer, 5/8
(Superseded to 736-04602)

$3.99

$

In Stock, Qty 20+

0

18

Cub Cadet 01005851

External Washer, 3/8
(Superseded to 736-0148)

$3.99

$

In Stock, Qty 20+

0

19

Cub Cadet 01007312

Spacer, .625 OD x .385 ID x 1/2

$22.99

$

Usually ships in 3-6 days

0

20

Cub Cadet 01009897

Flat Washer, .890 x 1.50 x .093

$6.49

$

In Stock, Qty 6

0

21

Cub Cadet 02000561-0637

Deck Link

$

$

Not available

22

Cub Cadet 02000671

Lock Washer, 5/8
(Superseded to 936-0158)

$4.49

$

In Stock, Qty 11

0

23

Cub Cadet 02002629

Extension Spring, 8.246 x .75 x .135

$18.99

$

Usually ships in 3-6 days

0

24

Cub Cadet 02002879

Front Lift Rod

$38.99

$

In Stock, Qty 10

0

25

Cub Cadet 02002880-0637

Foot Pedal Assembly

$

$

Not available

26

Cub Cadet 02002882

Foot Lift Torsion Spring

$10.99

$

In Stock, only 1 left!

0

27

Cub Cadet 02002907

Clevis Pin, .375 x 1.89 x 2.125
(Superseded to 711-06098)

$4.49

$

In Stock, only 3 left!

0

28

Cub Cadet 02003436

Spacer, .380 ID x .500 OD x .605

$6.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 02003751

Spacer, .635 ID x 1.188 OD x .406
(Superseded to 750-05621)

$4.49

$

In Stock, Qty 16

0

30

Cub Cadet 02004227

Trail Link Pivot Rod

$56.99

$

Usually ships in 3-6 days

0

31

Cub Cadet 02004409

Spacer, .889 x 1.25 x 1.25

$

$

Not available

32

Cub Cadet 02004436

Front Shaft Assembly

$

$

Not available

33

Cub Cadet 02004443

Deck Link

$

$

Not available

34

Cub Cadet 02004911

Bellcrank Lift Weldment Assembly

$30.99

$

Usually ships in 3-6 days

0

35

Cub Cadet 02004912-0637

Index Plate

$

$

Not available

36

Cub Cadet 02004929

Rear Shaft Assembly

$143.99

$

Usually ships in 3-6 days

0

37

Cub Cadet 02004927

Flange Bearing, 1.5 Hex, 7/8 ID

$16.99

$

Usually ships in 3-6 days

0

38

Cub Cadet 710-0514

Hex Cap Screw, 3/8-16 x 1.00

$4.49

$

In Stock, Qty 20+

0

39

Cub Cadet 912-3015

Jam Nut, 5/8-11
(Superseded to 712-3015)

$4.99

$

In Stock, Qty 20+

0

40

Cub Cadet 938-0380

Shoulder Screw, .50 x .27 Lg., 3/8-16
(Superseded to 738-0380)

$7.99

$

In Stock, only 1 left!

0
