SZL48-22KT - Scag Liberty Z 48" Zero-Turn Mower, 22hp Kohler (SN: K7100400 - K7199999) 48 & 52 Cutter Decks Parts Diagram

Liberty Z 48" Zero-Turn Mower, 22hp Kohler

48 & 52 Cutter Decks Parts Diagram

  • Title

1

Scag 485350

Belt, Cutter Deck -48

$75.99

$

In Stock, Qty 6

0

1

Scag 485424

Belt, Cutter Deck - 52

$77.99

$

In Stock, only 1 left!

0

2

Scag 424615

Bracket, Belt Guide

$5.49

$

Usually ships in 2-12 days

0

3

Scag 04021-09

Nut, 3/8-16 x 16 Elastic Stop

$0.99

$

In Stock, Qty 20+

0

4

Scag 04043-04

Flatwasher, 3/8-.391 x .938 x .105

$0.99

$

In Stock, Qty 20+

0

5

Scag 424367

Dust Shield

$2.49

$

In Stock, only 2 left!

0

6

Scag 04112-06

Nut, 3/4-16 Spiral Lock

$11.99

$

In Stock, Qty 5

0

7

Scag 04063-01

Key, 1/4 x 1/4 x 1-1/4"

$1.49

$

In Stock, only 4 left!

0

8

Scag 483422

Pulley, 5" Idler

$20.99

$

In Stock, Qty 8

0

9

Scag 483323

Pulley, 5.13" OD - 25mm Bore

$32.99

$

In Stock, only 2 left!

0

9

Scag 483324

Pulley, 5.73" OD - 25mm Bore

$32.99

$

In Stock, only 3 left!

0

10

Scag 426729

Belt Cover, SZL

$49.99

$

In Stock, only 1 left!

0

11

Scag 424479

Brace, Pulley

$5.49

$

Usually ships in 2-12 days

0

12

Scag 43711

Spacer

$6.49

$

Usually ships in 2-12 days

0

13

Scag 424548

Support, Idler Pivot - 48

$16.99

$

In Stock, only 1 left!

0

13

Scag 424547

Support, Idler Pivot - 52

$15.99

$

Usually ships in 2-12 days

0

14

Scag 04021-22

Nut, 5/16-18 Elastic Stop Grade 8

$0.99

$

In Stock, Qty 20+

0

15

Scag 04030-03

Lockwasher, 5/16"

$0.99

$

In Stock, Qty 20+

0

16

Scag 483453-03

Bearing, 1" ID

$7.99

$

In Stock, only 2 left!

0

17

Scag 462037

Idler Arm Assembly

Note: (incl. 16)

$75.99

$

In Stock, only 1 left!

0

18

Scag 04001-31

Bolt, Hex Head 3/8-16 x 2-1/2"

$0.99

$

In Stock, Qty 20+

0

19

Scag 43708

Pivot, Idler

$31.99

$

In Stock, only 1 left!

0

20

Scag 483375

Spring, Cutter Deck Idler

$85.99

$

In Stock, only 1 left!

0

21

Scag 04001-136

Bolt, Hex Head 3/8-16 x 1-1/2" Gr.8

$0.99

$

In Stock, Qty 20+

0

22

Scag 04019-04

Nut, 3/8-16 Serrated Flange

$0.99

$

In Stock, Qty 20+

0

23

Scag 04021-07

Nut, 1/2-13 Elastic Stop

$0.99

$

In Stock, Qty 20+

0

24

Scag 48114-04

Grease Fitting, 1/4-28 Self Tap

$0.99

$

In Stock, Qty 20+

0

25

Scag 462769

Pusharm Assembly, LH

Note: (incl. 24)

$75.99

$

Usually ships in 2-12 days

0

25

Scag 462770

Pusharm Assembly, RH

Note: (incl. 24)

$57.99

$

Usually ships in 2-12 days

0

26

Scag 43985

Spacer, Pusharm - Deck

$4.99

$

Usually ships in 2-12 days

0

27

Scag 43986

Spacer, Pusharm - Axle

$4.49

$

Usually ships in 2-12 days

0

28

Scag 04040-07

Flatwasher, 1/2-.531 x 1.062 x .095

$0.99

$

In Stock, Qty 5

0

29

Scag 04001-145

Bolt, Hex Head 1/2-13 x 3-1/2"

$2.49

$

In Stock, only 3 left!

0

30

Scag 04001-52

Bolt, Hex Head 1/2-13 x 2-1/2"

$1.49

$

Usually ships in 2-12 days

0

31

Scag 04011-29

Screw, 1/4-20 x .375"

$0.99

$

In Stock, Qty 5

0

32

Scag 461950

Spindle Assembly

$137.99

$

Usually ships in 2-12 days

0

33

Scag 483304

Debris Shield

$6.49

$

In Stock, only 1 left!

0

34

Scag 483303

Bearing

$13.99

$

In Stock, Qty 11

0

35

Scag 43693

Spacer

$22.99

$

Usually ships in 2-12 days

0

36

Scag 462014

Spindle Housing

Note: (incl. 34, 35)

$129.99

$

In Stock, only 1 left!

0

37

Scag 43694

Protector, Bearing

$28.99

$

In Stock, only 1 left!

0

38

Scag 43695

Shaft, Spindle

$49.99

$

In Stock, only 1 left!

0

39

Scag 04001-121

Bolt, Hex Head 5/8-11 x 1-1/2"

$1.99

$

In Stock, Qty 20+

0

40

Scag 04030-07

Lockwasher, 5/8"

$0.99

$

In Stock, Qty 19

0

41

Scag 04043-06

Flatwasher, 5/8-.688 x 1.75 x .134 HD

$1.99

$

In Stock, Qty 20+

0

42

Scag 482877

Cutter Blade, 16-1/2"

$22.99

$

In Stock, Qty 20+

0

42

Scag 482878

Cutter Blade, 18"

$23.99

$

In Stock, Qty 20+

0

43

Scag 04001-175

Bolt, Hex Head 5/16-18 x 1-1/2" Gr.8

$0.99

$

Usually ships in 2-12 days

0

44

Scag 04003-26

Bolt, Carriage 3/8-16 x 4"

$1.99

$

In Stock, Qty 20+

0

45

Scag 481632

Wheel, Anti-Scalp

$21.99

$

In Stock, Qty 20+

0

46

Scag 04017-27

Bolt, Hex Head Serr. Flange 3/8-16 x 1"

$1.49

$

In Stock, Qty 20+

0

47

Scag 04021-05

Nut, 3/8-16 Center Lock

$0.99

$

In Stock, Qty 20+

0

48

Scag 422478

Bracket, Anti-Scalp

$28.99

$

In Stock, Qty 20+

0

49

Scag 04001-77

Bolt, Hex Head 3/8-16 x 3-1/2"

$1.49

$

In Stock, Qty 7

0

50

Scag 04041-38

Flatwasher, 3/8-.406 x 2.250 x .188

$3.49

$

In Stock, Qty 8

0

51

Scag 451926

Shaft Weldment, Guide Roller

$25.99

$

In Stock, only 1 left!

0

52

Scag 482295

Wheel, Anti-Scalp

$9.99

$

In Stock, Qty 20+

0

53

Scag 04001-09

Bolt, Hex Head 5/16-18 x 1"

$0.99

$

In Stock, Qty 20+

0

54

Scag 04117-01

Nut, 5/16-18 Flange Elastic Stop

$0.99

$

In Stock, Qty 18

0

55

Scag 462794

Cutter Deck w/Decals

$

$

Not available

55

Scag 462795

Cutter Deck w/Decals
(Superseded to 463335)

$

$

Not available

56

Scag 462031

Discharge Chute

$65.99

$

In Stock, only 1 left!

0

56

Scag 462032

Discharge Chute

$71.99

$

Usually ships in 2-12 days

0

57

Scag 482245

Spring, Discharge Chute

$10.99

$

In Stock, Qty 5

0

58

Scag 04021-10

Nut, 5/16-18 Elastic Stop

$0.99

$

In Stock, Qty 20+

0

59

Scag 04001-154

Bolt, Hex Head 5/16-18 x 4-3/4"

$2.99

$

In Stock, Qty 20+

0

60

Scag 04001-12

Bolt, Hex Head 5/16-18 x 1-3/4"

$0.99

$

In Stock, Qty 20+

0
