SW 20 (5900965) - Snapper Pro SW20 Series 36" Walk-Behind Mower, 16hp Kawasaki EVAP Canister Group Parts Diagram

SW20 Series 36" Walk-Behind Mower, 16hp Kawasaki

EVAP Canister Group Parts Diagram

  • Title
1

Snapper Pro 313036

CNSTR, CARB, 6 GAL
(Superseded to 313036GS)

$217.99

$

Usually ships in 2-12 days

0

2

DECAL, EPA CERT, WALKS

Note: (Located on frame near Serial Tag)

$

$

Not available

3

Snapper Pro 5103055

CLAMP, 3" ID, CUSHIONED, STAINLESS
(Superseded to 5103055YP)

$7.99

$

Usually ships in 2-12 days

0

4

Snapper Pro 5025299X6

USE 5106757 - SCREW,1/4-20X3/4, ZINC
(Superseded to 5106757)

$3.49

$

Usually ships in 2-12 days

0

5

Snapper Pro 5025391

NUT, 1/4-20 HEX NYLOCK FLANGE
(Superseded to 5025391FS)

$3.99

$

In Stock, Qty 20+

0

6

Snapper Pro 770552X43

HOSE, VAPOR, 5MM ID, 43.00 LG

$

$

Currently unavailable

7

Snapper Pro 7700552X16

HOSE, VAPOR, 5MM ID, 16.00 LG
(Superseded to 7700552X22YP)

$8.99

$

Usually ships in 2-12 days

0

8

Snapper Pro 5103082

FITTING, 90 DEG, 3/16X3/16, SANTOPRENE
(Superseded to 5103082YP)

$10.99

$

Usually ships in 2-12 days

0

9

Snapper Pro 5103084

FITTING, STRAIGHT, 3/16X3/16, PLASTIC
(Superseded to 5103084YP)

$10.99

$

In Stock, only 2 left!

0
