ST 385i (UT-15173) - Homelite String Trimmer Carburetor - Fuel Tank Parts Diagram

String Trimmer

Carburetor - Fuel Tank Parts Diagram

  • Title

1

Homelite UP00020

FUEL TANK KIT
(Superseded to UP00020A)

Note: (Includes 2-9)

$

$

Not available

2

Homelite UP00106

FUEL CAP (1 5/8" Opening)
(Superseded to 300758006)

$

$

Not available

3

Homelite 98792

BUMPER-Rubber

$1.49

$

Usually ships in 3-7 days

0

4

Homelite 0143918

TUBING-Rubber

$

$

Not available

5

Homelite 0143910

TUBING-Rubber

$1.99

$

In Stock, Qty 5

0

6

Homelite 9477213

TUBING-Rubber

$

$

Not available

7

Homelite 49422

FUEL FILTER
(Superseded to PS03380)

$

$

Not available

8

Homelite 02067

FITTING

$

$

Not available

9

Homelite 98268

CLAMP
(Superseded to 690765001)

$1.99

$

In Stock, Qty 7

0

10

Homelite 04474

SCREW-Machine (10-24 x 2 1/4")

Note: (Torque Specs 30-40 In/Lbs, 3.4-4.5 Nm)

$

$

Not available

11

Homelite 98768A

HEAT DAM
(Superseded to 518070001)

$

$

Not available

12

Homelite 093221

SCREW, SEMS (10-24 x 1")
(Superseded to 660662001)

Note: (Torque Specs 40-50 In/Lbs, 4.5-5.6 Nm, Red 262 Required Loctite)

$

$

Not available

13

Homelite A04445A

CARBURETOR KIT

Note: (Includes 14-16)

$

$

Not available

14

Homelite 98766A

GASKET-Carburetor
(Superseded to 900994004)

$

$

Not available

15

Homelite 07376

LEVER-Choke (Walbro)

$

$

Not available

Homelite PS00236

LEVER-Choke (Zama)
(Superseded to UP04278)

$

$

Not available

16

Homelite 06900A

GASKET-Heat Dam

$

$

Not available
