SSZ-18CV - Scag Super Z Zero-Turn Mower, 18hp Kohler (SN: 50000 - 59999) CUTTER DECK CONTROLS 52" & 61" DECKS Parts Diagram

Super Z Zero-Turn Mower, 18hp Kohler

CUTTER DECK CONTROLS 52" & 61" DECKS Parts Diagram

  • Title

1

Scag 45524

BELLCRANK, LIFT - RIGHT FRONT

$

$

Not available

2

Scag 48100-05

BUSHING

$0.99

$

In Stock, only 3 left!

0

3

Scag 45527

LIFT LINK

$50.99

$

Usually ships in 2-12 days

0

7

Scag 04017-17

BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 1"

$0.99

$

Usually ships in 2-12 days

0

8

Scag 46384

HEIGHT ADJUSTMENT LEVER(INCLUDES GRIP)

$

$

Not available

9

Scag 48093

GRIP, LEVER LIFT

$1.99

$

In Stock, only 1 left!

0

10

Scag 44065

ROD, CUTTER DECK LOCK

$

$

Not available

11

Scag 48053

SPRING, DECK LIFT INDEX

$5.99

$

Usually ships in 2-12 days

0

13

Scag 42887

LOCK, ROD GUIDE

$31.99

$

Usually ships in 2-12 days

0

14

Scag 04019-04

NUT, SERRATED FLANGE HEX 3/8-16

$0.99

$

In Stock, Qty 20+

0

16

Scag 48114-04

GREASE FITTING

$0.99

$

In Stock, Qty 20+

0

18

Scag 42828

STRIP, HEIGHT ADJUSTMENT

$132.99

$

Usually ships in 2-12 days

0

22

Scag 04021-09

NUT, ELASTIC STOP 3/8-16

$0.99

$

In Stock, Qty 20+

0

23

Scag 04040-09

FLATWASHER, 5/8"(.656 X 1.312 X .075)

$0.99

$

In Stock, Qty 12

0

24

Scag 45313

BELLCRANK, LIFT - LEFT FRONT

$

$

Not available

25

Scag 43271

SWIVEL JOINT - LH THD

$

$

Not available

27

Scag 04040-10

FLATWASHER, 5/8"(.688 X 1.75 X .134)

$0.99

$

In Stock, Qty 11

0

29

Scag 04001-20

BOLT, HEX HEAD 3/8-16 X 1-1/2"

$0.99

$

In Stock, Qty 20+

0

30

Scag 04020-09

NUT, HEX 5/8-11

$0.99

$

In Stock, Qty 20+

0

31

Scag 43270

SWIVEL JOINT - RH

$

$

Not available

33

Scag 45427

BELLCRANK

$

$

Not available

34

Scag 04063-15

KEY, 3/16 X 3/16 X .75"

$18.99

$

In Stock, only 2 left!

0

35

Scag 48114-05

GREASE FITTING

$1.49

$

In Stock, Qty 9

0

37

Scag 04001-45

BOLT, HEX HEAD 3/8-16 X 2"

$0.99

$

In Stock, Qty 8

0
