SRS Z2 (5901605) - Ferris SRS Z2 Series 52" Stand-On Mower, 28hp Briggs & Stratton Neutral Lockout Group S/N: 4000089208 and Below Parts Diagram

SRS Z2 Series 52" Stand-On Mower, 28hp Briggs & Stratton

Neutral Lockout Group S/N: 4000089208 and Below Parts Diagram

  • Title
1

Ferris 5414055A

WELD, NEUTRAL LOCK SHAFT - BLK
(Superseded to 5414055AFS)

$37.99

$

Usually ships in 2-12 days

0

2

Ferris 5101123

BEARING, 1/2 FLANGED, PLASTIC BALL
(Superseded to 5101123SM)

$5.99

$

Usually ships in 2-12 days

0

3

Ferris 5025011X16

BOLT, 5/16-18 X 2 GD5 CZ
(Superseded to 5025011X16YP)

$3.99

$

Usually ships in 2-12 days

0

4

Ferris 5025127

NUT, 5/16-18 HEX SERRATED FLANGE (SMALL)
(Superseded to 5025127SM)

$3.49

$

In Stock, Qty 7

0

5

Ferris 5025010X6

BOLT, 1/4-20 X 3/4 GD5 CZ
(Superseded to 5025010X6SM)

$3.99

$

In Stock, Qty 20+

0

6

Ferris 5025154

WASHER, 1/4 SAE
(Superseded to 84007033)

$4.49

$

Usually ships in 2-12 days

0

7

Ferris 5025391

NUT, 1/4-20 HEX NYLOCK FLANGE
(Superseded to 5025391FS)

$3.99

$

In Stock, Qty 20+

0

8

Ferris 5025011X18

BOLT, 5/16-18 X 2-1/4 GD5 CZ
(Superseded to 5025011X18SM)

$3.99

$

In Stock, only 1 left!

0

9

Ferris 5025213X8

PIN, CLEVIS, 5/16 X 1, PLATED
(Superseded to 5025213X8SM)

$4.99

$

Usually ships in 2-12 days

0

10

Ferris 5025211

PIN, HAIR, .0585 X 1-1/8, 1/4 EYE, CZ
(Superseded to 5025211SM)

$3.99

$

In Stock, only 1 left!

0

11

Ferris 5104695

ROD, 5/16-24 X 3.25, CZ
(Superseded to 5104695FS)

$5.99

$

Usually ships in 2-12 days

0

12

Ferris 5023323

CLEVIS, 5/16-24, STEEL, CLEAR ZINC
(Superseded to 5023323SM)

$9.49

$

Usually ships in 2-12 days

0

13

Ferris 5025033

NUT, 5/16-24 HEX
(Superseded to 5025033FS)

$3.49

$

Usually ships in 2-12 days

0

14

Ferris 5023212

NUT, 5/16-24 HEX, LH
(Superseded to 5023212SM)

$3.49

$

Usually ships in 2-12 days

0

15

Ferris 5025011X10

BOLT, 5/16-18 X 1-1/4 GD5 CZ
(Superseded to 5025055X10YP)

$3.49

$

In Stock, only 2 left!

0

16

Ferris 5104494

BALL JOINT 5/16-24 LH FEMALE BRONZE RACE
(Superseded to 5104494YP)

$18.99

$

Usually ships in 2-12 days

0

17

Ferris 5025337

WASHER, 5/16 USS
(Superseded to 5025337FS)

$3.99

$

Usually ships in 2-12 days

0

18

Ferris 5025392

NUT, 5/16-18 HEX NYLOCK FLANGE
(Superseded to 5025392FS)

$3.49

$

Usually ships in 2-12 days

0

19

SEE PARKING BRAKE GROUP

$

$

Not available
