Speed ZTR 42 (966808404) - Dixon 42" Speed ZTR Zero-Turn Mower (2013-09) IGNITION SYSTEM Parts Diagram

42" SpeedZTR Zero-Turn Mower

IGNITION SYSTEM Parts Diagram

  • Title

1

Dixon 539120193

FENDER RH

$56.99

$

Usually ships in 3-10 days

0

2

Dixon 539120192

FENDER LH

$56.99

$

Usually ships in 3-10 days

0

3

Dixon 532109553

No Description Available
(Superseded to 539101080)

$20.99

$

In Stock, Qty 20+

0

4

Dixon 539107541

IGNITION SWITCH
(Superseded to 532175566)

$28.99

$

In Stock, Qty 20+

0

5

Dixon 532176138

SWITCH INTERLOOK PUSH-IN

$22.99

$

In Stock, Qty 20+

0

6

Dixon 539101714

SOLENOID

$28.99

$

Usually ships in 3-10 days

0

7

Dixon 539107628

BATTERY HOLD DOWN

$10.99

$

In Stock, Qty 5

0

8

Dixon 539107544

OBSOLETE - KEY
(Superseded to 532140401)

$6.99

$

In Stock, Qty 20+

0

9

Dixon 539120178

CONTROL PANEL MT.

$

$

Not available

10

Dixon 539120222

THROTTLE CABLE

$

$

Not available

11

Dixon 532193235

CABLE.CLUTCH.38".SERVICE

$56.99

$

In Stock, Qty 13

0

12

Dixon 575661501

ASM, CLUTCH ENGAGE W/CABLE

$62.99

$

Usually ships in 3-10 days

0

13

Dixon 539132624

KNOB - SHIFT

$7.99

$

In Stock, Qty 5

0

14

Dixon 539116400

TERMINAL COVER-SM

$3.99

$

Usually ships in 3-10 days

0

15

Dixon 576646403

FUEL TANK ASM SMALL

$262.99

$

Usually ships in 3-10 days

0

16

Dixon 575018101

CAP, FUEL
(Superseded to 575018103)

$37.99

$

In Stock, only 3 left!

0

17

Dixon 539110432

OBSOLETE - STEM, FUEL TANK
(Superseded to 532139277)

$8.99

$

In Stock, Qty 20+

0

18

Dixon 539102436

OBSOLETE - BATTERY, 12 V 330 AMP TBR
(Superseded to 579411601)

$

$

Not available

19

Dixon 539105245

RUBBER GROMMET

$4.99

$

In Stock, Qty 20+

0

20

Dixon 576618201

GROMMET, CHECK VALVE
(Superseded to 584648201)

$4.99

$

In Stock, Qty 20+

0

21

Dixon 539105974

OBSOLETE - RUBBER GROMMET

$

$

Not available

22

Dixon 539916325

FUEL VALVE

$47.99

$

In Stock, only 2 left!

0

23

Dixon 576618101

VALVE.FUEL.CHECK

$28.99

$

In Stock, Qty 20+

0

24

Dixon 539912222

HOSE CLAMP

$4.99

$

In Stock, only 1 left!

0

25

Dixon 575436501

CLAMP, HOSE

$6.49

$

In Stock, Qty 13

0

26

Dixon 539115736

HOSE 1/4 X 8

$7.99

$

Usually ships in 3-10 days

0

27

Dixon 539121486

HOSE 1/4 X 2"

$3.99

$

Usually ships in 3-10 days

0

28

Dixon 574521305

HOSE, FUEL, 3/16" X 20"

$17.99

$

Usually ships in 3-10 days

0

29

Dixon 505280001

TIE WRAP, 8-3/8", W/CLIP

$3.99

$

In Stock, only 2 left!

0

30

Dixon 539104974

POST.CABLE LONG

$

$

Not available

31

Dixon 539103306

CABLE POSITIVE, LONG
(Superseded to 586108201)

$11.99

$

In Stock, only 1 left!

0

32

Dixon 539110068

BATTERY CABLE, NEGATIVE

$9.49

$

Usually ships in 3-10 days

0

33

Dixon 539990580

HCS 1/4C X 3/4 HCS

$3.99

$

Usually ships in 3-10 days

0

34

Dixon 539976952

SCREW #10-24 X 5/8
(Superseded to 596039001)

$3.99

$

In Stock, Qty 19

0

35

Dixon 539990316

BOLT 5/16C X 3/4" CARRIAGE
(Superseded to 595901601)

$3.99

$

In Stock, Qty 20+

0

36

Dixon 539990074

RHSNB 1/4C X 3/4
(Superseded to 596238401)

$3.99

$

Usually ships in 3-10 days

0

37

Dixon 539107632

BOLT - 1/4-20 X 7.5

$

$

Not available

38

Dixon 539990362

SCREW 1/4 X 5/8

$4.99

$

In Stock, Qty 12

0

39

Dixon 539990055

WASHER 1/4 SAE

$3.99

$

In Stock, Qty 19

0

40

Dixon 539112899

5/16-18 NYLOC FLANGE NUT
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

41

Dixon 539107629

PUSH NUT-NYLON

$4.99

$

In Stock, only 1 left!

0

42

Dixon 539976977

NUT 10-24 NYLOC

$

$

Not available

43

Dixon 539976978

NUT 1/4-20 NYLOC
(Superseded to 582478602)

$2.49

$

In Stock, Qty 20+

0

Dixon 574658201

HARNESS, WIRING

Note: NOT SHOWN

$148.99

$

Usually ships in 3-10 days

0
