Speed ZTR 36 (965882201) - Dixon 36" Speed ZTR Zero-Turn Mower (2009-05) SEAT Parts Diagram

36" SpeedZTR Zero-Turn Mower

SEAT Parts Diagram

  • Title

1

Dixon 539121381

SEAT ASSEMBLY
(Superseded to 539116143)

$

$

Not available

2

522854202

$

$

Not available

3

522854201

$

$

Not available

4

Dixon 539990188

FLAT WASHER 5/16 SAE
(Superseded to 819111116)

$3.99

$

In Stock, Qty 20+

0

5

Dixon 539115566

5/16-18X1 HHB G5W/NY
(Superseded to 874950516)

$

$

Not available

6

Dixon 539115789

WASHER NYLON

$3.99

$

Usually ships in 3-10 days

0

7

Dixon 539108388

SCR 1/4-20X3/4 SLTD RDHD GR2ZD

$2.49

$

Usually ships in 3-10 days

0

8

Dixon 539117398

SEAT SWITCH MILSCO

$34.99

$

Usually ships in 3-10 days

0

9

Dixon 539103247

SEAT LANYARD

$21.99

$

In Stock, only 2 left!

0

10

Dixon 539122380

SEAT BACK

$

$

Not available

11

Dixon 539118102

CLIP-1.06

$7.49

$

Usually ships in 3-10 days

0

12

Dixon 539976935

CAPSCREW 5/16 X 1/1/2 HEX HEAD

$

$

Not available

13

Dixon 522858101

ARMREST
(Superseded to 539121719)

$

$

Not available

14

Dixon 539990692

WASHER 5/16 FLAT
(Superseded to 819121414)

$3.49

$

Usually ships in 3-10 days

0

15

Dixon 525811504

PAN, SEAT, BLUE

$122.99

$

Usually ships in 3-10 days

0

16

Dixon 522506902

SUPPORT, SEAT MED FLAT, BLUE

$242.99

$

Usually ships in 3-10 days

0

17

Dixon 510182902

SUPPORT, REAR SEAT, BLACK

$66.99

$

Usually ships in 3-10 days

0

18

Dixon 539110300

SPRING, SEAT
(Superseded to 587613301)

$6.99

$

In Stock, only 4 left!

0

19

Dixon 539976941

HCS 3/8C X 1 1/4 GR5

$4.99

$

In Stock, only 2 left!

0

20

Dixon 539990517

WASHER 3/8 FLAT

$3.99

$

Usually ships in 3-10 days

0

21

Dixon 539990122

WASHER 3/8 SAE FLAT
(Superseded to 596565301)

$3.99

$

In Stock, Qty 20+

0

22

Dixon 539976979

NUT 3/8-16 NYLOC
(Superseded to 596240901)

$3.99

$

In Stock, Qty 20+

0

23

Dixon 539102587

GROMMET, BUMPER

$5.99

$

In Stock, Qty 15

0

24

Dixon 539104763

U-CLIP 5/16-18 NUT RETAINER

$6.49

$

In Stock, Qty 12

0

25

Dixon 510231302

BOX, BATTERY, BLACK

$182.99

$

Usually ships in 3-10 days

0

26

Dixon 539990645

RHSNB 3/8C X 1

$

$

Not available

27

Dixon 539107475

BOLT 5/16-18 X 3/4

$6.49

$

In Stock, only 4 left!

0

28

Dixon 539130896

SB 5/16-18 HEX HD GD5, BLK ZN

$17.99

$

Usually ships in 3-10 days

0

29

Dixon 539112899

5/16-18 NYLOC FLANGE NUT
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

Dixon 522875901

SEAT ASSY, FIXED ARM
(Superseded to 525597201)

Note: NOT SHOWN

$424.99

$

Usually ships in 3-10 days

0
