SG 13 (968999239) - Husqvarna Stump Grinder (2005-12) BLADE DRIVE & DEPTH CONTROL 2 Parts Diagram

Stump Grinder

BLADE DRIVE & DEPTH CONTROL 2 Parts Diagram

  • Title

539 02 02-32

Husqvarna 539020232

KIT, THREADED POCKET

$

$

Not available

539 20 07-52

Husqvarna 539200752

KIT CUTTING TEETH COMPLETE

Note: CUTTING TEETH, COMPLETE (INCLUDES) RIGHT TOOTH (4 EA) LEFT TOOTH (4 EA)

$364.99

$

Usually ships in 3-10 days

0

539 11 01-44

Husqvarna 539110144

ALLEN WRENCH 1/2" X 8" LG MIN

Note: NOT SHOWN: ALLEN WRENCH

$

$

Not available

539 02 02-27

Husqvarna 539020227

KIT CUTTING WHEEL

Note: NO TEETH

$667.99

$

Usually ships in 3-10 days

0

539 02 02-26

Husqvarna 539020226

BEARING KIT STUMPGRINDER

Note: BEARING, FLANGE (INCLUDES) BEARING (1 EA) BOLT 3/8-16 X 1 3/4 (4 EA) WASHER 3/8, FLAT (4 EA) NUT 3/8, LOCK (4 EA)

$113.99

$

Usually ships in 3-10 days

0

539 02 02-31

Husqvarna 539020231

KIT, COUNTER BORE POCKET

$

$

Not available

539 02 02-28

Husqvarna 539020228

KIT, CUTTING TEETH SET, S G

Note: COMPLETE SET OF CUTTING TEETH (INCLUDES) COUNTER BORE POCKET (4 EA) THREADED POCKETS (4 EA) LEFT TOOTH (4 EA) RIGHT TOOTH (4 EA) SOCKET HEAD SCREWS (8

$

$

Not available

539 02 02-29

Husqvarna 539020229

KIT RT TOOTH STUMP GRINDER
(Superseded to 539020031)

Note: RIGHT

$22.99

$

In Stock, only 2 left!

0

540 02 02-25

Husqvarna 540020225

CUTTING SHROUD W/DECAL

Note: KIT, CUTTING WHEEL SHROUD (INCLUDES) SHROUD W/DECAL BOLT, 3/8-16 X 1 (4 EA) LOCKWASHER 3/8 (4 EA) WASHER 3/8, FLAT (4 EA)

$376.99

$

Usually ships in 3-10 days

0

539 02 02-30

Husqvarna 539020230

KIT LEFT TOOTH STUMP GRINDER
(Superseded to 539020032)

Note: LEFT

$22.99

$

In Stock, only 2 left!

0

539 02 02-33

Husqvarna 539020233

KIT POCKET BOLTS STUMP GR

Note: 2 EA REQUIRED PER POCKET

$

$

Not available
