SC 3306 - Bear Cat 3" Chipper/Shredder, 306cc Briggs & Stratton (SN: E05977 & Above) Engine - Single Belt Parts Diagram

3" Chipper/Shredder, 306cc Briggs & Stratton

Engine - Single Belt Parts Diagram

  • Title

1

15118-00

BOLT, 5/16 X 3/4 SERRATED FLANGE NF

$

$

Not available

2

15122-00

BOLT, 5/16 X 1-1/2 FLANGE NC

$

$

Not available

6

Bear Cat 15418

KEY, 1/4 SQUARE X 1-1/2 LONG PLAIN

$

$

Not available

8

Bear Cat 15904-00

NUT, 5/16-18 NYLOCK-FLANGE

$

$

Not available

9

Bear Cat 16043

BELT, 29" C/S

$63.99

$

Usually ships in 3-7 days

0

12

Bear Cat 17958

PULLEY, CAST 4" OD 1" BORE B GRV

$83.99

$

Usually ships in 3-7 days

0

13

ENGINE, 306CC B&S HORIZONTAL ELECTRIC

Note: (FOR SERVICE SEE ENGINE OWNERS MANUAL OR YOUR NEAREST BRIGGS & STRATTON INDUSTRIAL ENGINE DEALER)

$

$

Not available

13

ENGINE, 306CC B&S HORIZONTAL

Note: (FOR SERVICE SEE ENGINE OWNERS MANUAL OR YOUR NEAREST BRIGGS & STRATTON INDUSTRIAL ENGINE DEALER)

$

$

Not available

16

Bear Cat 74249-12

PLATE, ENGINE MOUNTING

$

$

Not available

17

Bear Cat 74374-12

GUIDE, BELT

$

$

Not available

Bear Cat 36230-00

TERMINAL, 14/16 GA ELECTRICAL - SC3306E ONLY

Note: (NOT SHOWN)

$1.99

$

Usually ships in 3-7 days

0
