SB-140 (31A-140-000) - White Outdoor Snow Boss Snow Thrower (2001) Controls And Shroud Parts Diagram

Snow Boss Snow Thrower

Controls And Shroud Parts Diagram

  • Title

1

White Outdoor 684-0056

Dash-21"

Variations

White Outdoor 684-0056-0498

No Longer Available PANEL-DASH - OLD CUB YELLOW (0498)

$

$

Not available

White Outdoor 684-0056-0629

PANEL-DASH - SILVER FLAKE (0629)

$

$

Not available

White Outdoor 684-0056-0637

PANEL-DASH - POWDER BLACK (0637)

$

$

Not available

White Outdoor 684-0056-0638

PANEL-DASH - MTD/TROY-BILT RED (0638)

$

$

Not available

White Outdoor 684-0056-0662

Dash-21" - OYSTER GRAY (0662)

$

$

Not available

$

$

2

White Outdoor 710-1090

Hex Flange Screw

$3.99

$

Usually ships in 3-6 days

0

3

White Outdoor 710-0895

Hex Tap Screw

$6.49

$

Usually ships in 3-6 days

0

4

White Outdoor 710-1268

Hex Tap Screw

$4.49

$

In Stock, Qty 20+

0

5

White Outdoor 712-0252

Hex Nut

$5.99

$

Usually ships in 3-6 days

0

6

White Outdoor 712-3010

Hex Nut

$4.49

$

In Stock, Qty 20+

0

7

White Outdoor 714-0104

Cotter Pin

$4.49

$

In Stock, Qty 20+

0

8

UNKNOWN

$

$

Not available

9

White Outdoor 720-0201A

Chute Crank Knob

$10.99

$

In Stock, Qty 5

0

10

White Outdoor 725-0201

Key-Ignition
(Superseded to 925-0201)

$9.49

$

In Stock, only 1 left!

0

11

White Outdoor 725-1425

Switch-Key
(Superseded to 925-1425)

$35.99

$

In Stock, Qty 6

0

12

White Outdoor 726-0100

Nut Push

$4.49

$

In Stock, Qty 20+

0

13

White Outdoor 731-0702

Shroud

$

$

Not available

14

White Outdoor 731-1133B

Plug
(Superseded to 731-1133C)

$

$

Not available

15

White Outdoor 736-0119

Lock Washer
(Superseded to 936-0119)

$4.99

$

In Stock, Qty 20+

0

16

White Outdoor 736-0185

Flat Washer

$3.99

$

In Stock, Qty 20+

0

17

White Outdoor 736-0225

Internal Lock Washer

$4.49

$

In Stock, only 2 left!

0

18

White Outdoor 736-0400

Flat Washer

$5.49

$

In Stock, Qty 12

0

20

White Outdoor 741-0475

Bushing
(Superseded to 941-0475)

$4.49

$

In Stock, Qty 20+

0

21

White Outdoor 784-5178A

Bracket, Chute Crank

$

$

Not available

22

White Outdoor 784-5344

Crank Assembly, Chute

$

$

Not available

23

White Outdoor 714-0111

Cotter Pin

Note: Optional chute crank assembly on Model 140 only

$4.99

$

In Stock, Qty 13

0

24

White Outdoor 747-0737

Chute Crank-Upper
(Superseded to 747-0737-0637)

Note: Optional chute crank assembly on Model 140 only

Variations

White Outdoor 747-0737-0637

Upper Chute Crank Black - POWDER BLACK (0637)

$45.99

$

Usually ships in 3-6 days

0

$45.99

$

Usually ships in 3-6 days

0

26

White Outdoor 684-0126

Chute Crank-Lower
(Superseded to 684-0126-0637)

Note: Optional chute crank assembly on Model 140 only

Variations

White Outdoor 684-0126-0637

CRANK-CHUTE LOWER - POWDER BLACK (0637)

$

$

Not available

$

$

27

White Outdoor 750-0785

Spacer
(Superseded to 950-0785)

Note: Optional chute crank assembly on Model 140 only

$32.99

$

Usually ships in 3-6 days

0

29

White Outdoor 735-0234

Grommet - Rubber

Note: Optional chute crank assembly on Model 140 only

$5.49

$

In Stock, only 2 left!

0

30

White Outdoor 747-0697

Eyebolt - Chute Crank

Note: Optional chute crank assembly on Model 140 only

$8.49

$

In Stock, only 1 left!

0

31

White Outdoor 712-3010

Nut - Hex

Note: Optional chute crank assembly on Model 140 only

$4.49

$

In Stock, Qty 20+

0

32

White Outdoor 736-0451

Washer-Saddle

Note: Optional chute crank assembly on Model 140 only

$4.49

$

In Stock, Qty 11

0
