S6031-KW (53AI8DU6050) - Cub Cadet 60" Tank S Zero-Turn Mower, 31hp Kawasaki Brake Pedal Assembly Parts Diagram

60" Tank S Zero-Turn Mower, 31hp Kawasaki

Brake Pedal Assembly Parts Diagram

  • Title

1

Cub Cadet 00006129

HHCS, 5/16-18 x 1-3/4

$6.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 00022547

Lock Nut, 5/16-18, Center

$

$

Not available

3

Cub Cadet 00022560

Flange Lock Hex Nut, 3/8-16
(Superseded to 712-05007)

$4.49

$

In Stock, Qty 20+

0

4

Cub Cadet 00061053

Washer, 3/8, SS

$3.99

$

Usually ships in 3-6 days

0

5

Cub Cadet 01004127

HHCS, 3/8-16 x 3.00
(Superseded to 710-0521)

$5.49

$

In Stock, Qty 11

0

6

Cub Cadet 750-05186-0637

Spacer, .385 ID x .625 OD x .458

$75.99

$

Usually ships in 3-6 days

0

7

Cub Cadet 02003436

Spacer, .380 x .500 x .667

$6.99

$

Usually ships in 3-6 days

0

8

Cub Cadet 02003666

HHCS, 3/8-16 x 3.50

$

$

Not available

9

Cub Cadet 02005568

Flange Bearing, .502 x .875 x .180

$

$

Not available

10

Cub Cadet 02005591

Torsion Spring

$

$

Not available

11

Cub Cadet 02005592

Torsion Spring

$

$

Not available

12

Cub Cadet 02005606P

Brake Cable, LH

$80.99

$

Usually ships in 3-6 days

0

13

Cub Cadet 02005607P

Brake Cable, RH

$87.99

$

Usually ships in 3-6 days

0

14

Cub Cadet 02005612-0637

Brake Carriage Assembly

$

$

Not available

15

Cub Cadet 603-04639-0637

Pedal Assembly, Brake

$

$

Not available

16

Cub Cadet 02005703

Roller Guide Brake Bracket

$

$

Not available

17

Cub Cadet 02005714

Brake Control Link

$

$

Not available

18

Cub Cadet 02005718

Lockout Control Plate

$

$

Not available

19

Cub Cadet 703-06975-0637

Brake Switch Mounting Bracket

$

$

Not available

20

Cub Cadet 703-06762

Park Engage Bracket

$

$

Not available

21

Cub Cadet 703-06766

Brake Bracket

$

$

Not available

22

Cub Cadet 711-05058

Pin, .500 x .804 LG

$

$

Not available

23

Cub Cadet 916-0104

E-Ring for .500 Dia. Shaft

$3.99

$

In Stock, Qty 20+

0

24

Cub Cadet 720-04108

Grip, Brake

$

$

Not available

25

Cub Cadet 736-04407

Washer, .531 ID x 1.50 OD x .08

$

$

Not available

26

Cub Cadet 736-04418

Washer, .39 ID x .62 OD x .03

$

$

Not available

27

Cub Cadet 738-04360

Shoulder Screw, .375 x 2.00 x 5/16-18

$

$

Not available

28

Cub Cadet 741-04371

Flange Bearing .375 ID x .875 OD

$4.99

$

Usually ships in 3-6 days

0

29

Cub Cadet 750-05071

Spacer, .319 x .375 x 1.056

$

$

Not available

30

Cub Cadet 750-05072

Spacer, .384 x .500 x 1.00

$

$

Not available

31

Cub Cadet 750-05178

Spacer, .38 ID x .50 OD x .955

$

$

Not available
