RZT-S42 Zero (17AVCEDS710) - Cub Cadet 42" RZT Zero-Turn Mower, Electric (2016) Deck Parts Diagram

42" RZT Zero-Turn Mower, Electric

Deck Parts Diagram

  • Title

1

Cub Cadet 603-05215A-4021

DECK HANGER BRACKET (LH)
(Superseded to 603-05215A-0637)

$66.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 903-05252-4021

42" DECK SHELL E

$553.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 703-09086-4021

ELECTRIC DECK COVER

$11.99

$

Usually ships in 3-6 days

0

4

Cub Cadet 710-0599

SCREW 1/4-20 X.500

$4.49

$

In Stock, Qty 20+

0

5

Cub Cadet 710-06012A

SCREW 3/8-16 x 1.25 GR5

$3.99

$

In Stock, Qty 7

0

6

Cub Cadet 710-1044

SCREW 3/8-24 x 1.50 GR8

$3.99

$

In Stock, only 1 left!

0

7

Cub Cadet 710-1260A

SCREW 5/16-18 x .750

$3.99

$

In Stock, Qty 20+

0

8

Cub Cadet 712-0130

HEX NUT INS L-3/8-16

$3.99

$

In Stock, Qty 13

0

9

Cub Cadet 712-04063

FLANGE LOCK NUT 5/16-18

$3.99

$

In Stock, Qty 20+

0

10

Cub Cadet 712-04065

NUT

$3.99

$

In Stock, Qty 20+

0

11

Cub Cadet 917-05298

DECK ADJUSTMENT GEAR

$13.99

$

In Stock, only 1 left!

0

12

Cub Cadet 921-04041

WATER NOZZLE

$23.99

$

In Stock, Qty 20+

0

13

Cub Cadet 924-04140

48v MOTOR

$954.99

$

Usually ships in 3-6 days

0

14

Cub Cadet 731-07487

DECK WASH NOZZLE

$4.49

$

In Stock, only 4 left!

0

15

Cub Cadet 734-04155

DECK WHEEL

$20.99

$

In Stock, Qty 20+

0

16

Cub Cadet 736-0182

SPRING WASHER .50 x 1.0 x .022

$4.49

$

In Stock, Qty 7

0

17

Cub Cadet 736-0524B

BLADE BELL SUPPORT
(Superseded to 736-0524B-1)

$5.99

$

In Stock, Qty 13

0

18

Cub Cadet 738-04502

SHOULDER SCREW 1/4-20 x .50

$4.49

$

In Stock, Qty 16

0

19

Cub Cadet 738-05092

SHOULDER BOLT .500 x 2.75 x 3/8-16

$23.99

$

Usually ships in 3-6 days

0

20

Cub Cadet 938-3056

SHOULDER BOLT

$9.49

$

In Stock, Qty 20+

0

21

Cub Cadet 942-04403

21.18" BLADE (MULCH)
(Superseded to 742-04403-0637)

$30.99

$

In Stock, only 3 left!

0

22

Cub Cadet 748-0376E

BLADE ADAPTER-W/STAR

$20.99

$

In Stock, only 2 left!

0

23

N/A

LABEL (NOT SERVICEABLE)

$

$

Not available
