RY BRC77 (090109015) - Ryobi Expand-It Blower Attachment General Assembly Parts Diagram

Expand-It Blower Attachment

General Assembly Parts Diagram

  • Title
1

Homelite 678018001

Blade Nut (M8, Left Hand Threads)
(Superseded to 04277)

$

$

Not available

2

Homelite 638017001

Cupped Washer
(Superseded to 04409)

$3.99

$

In Stock, only 1 left!

0

3

Homelite 638006004

Blade (Tri-Arc(R))

$21.99

$

In Stock, only 1 left!

0

4

Homelite 678011001

Flanged Washer
(Superseded to 099078001005)

$10.99

$

Usually ships in 3-7 days

0

5

Homelite 660737001

Screw w/Washer (10-24 x 1/2 in., Hex Hd)
(Superseded to 88049)

$

$

Not available

6

Homelite 638120004

Brush Cutter Guard

$25.99

$

Usually ships in 3-7 days

0

7

Homelite 308210008

Gear Head Assembly
(Superseded to 308210001)

$

$

Not available

8

Homelite 660641001

Screw (10-24 x 5/8 in.)

$1.99

$

Usually ships in 3-7 days

0

9

Homelite 660642001

Screw (1/4-20 x 1-1/4 in)
(Superseded to 983381007)

$2.49

$

In Stock, Qty 5

0

10

Homelite 308035058

Boom Assembly

Note: (Inc. Key Nos. 11-12 and 24)

$35.99

$

In Stock, only 3 left!

0

11

Homelite 518019002

Hanger Cap
(Superseded to 518019004)

$1.99

$

In Stock, Qty 6

0

12

Homelite 940657027

Warning Label

$

$

Not available

13

Homelite 638564001

Top "J" Handle Clamp

$2.49

$

Usually ships in 3-7 days

0

14

Homelite 638565001

Bottom "J" Handle Clamp

$2.49

$

Usually ships in 3-7 days

0

15

Homelite 660643001

Bolt (1/4-20 x 1-1/2 in., Hex Hd)

$1.99

$

Usually ships in 3-7 days

0

16

Homelite 308046005

"J" Handle and Grip
(Superseded to 308046009)

$27.99

$

In Stock, only 1 left!

0

17

Homelite 308224001

Strap Hanger
(Superseded to 07255)

$

$

Not available

18

Homelite 308487001

Shoulder Harness Assembly

$11.99

$

In Stock, only 1 left!

0

19

Homelite 678020001

Head Locking Tool
(Superseded to 099078001040)

$2.49

$

In Stock, only 4 left!

0

20

$1.99

$

In Stock, only 3 left!

0

21

$1.99

$

Usually ships in 3-7 days

0

22

Homelite 518949001

Wing Nut (1/4-20)
(Superseded to PS02453)

$2.49

$

In Stock, only 1 left!

0

23

Homelite 940705021

Logo Label

$

$

Not available

24

Homelite 940726013

Logo Label

$1.99

$

Usually ships in 3-7 days

0

Homelite 991000566

Operator's Manual

Note: NOT SHOWN

$

$

Not available
