RY 3818 VNM (095382011) - Ryobi Chainsaw, 38cc, Rev 02 (2021-08) FIGURE C Parts Diagram
Chainsaw, 38cc, Rev 02
FIGURE C Parts Diagram
Homelite 311455002
Crankcase & Crankshaft Assembly
Note: When replacing key 1, models before date code 7/30/21 must also order key 83B Flywheel Assembly on page 4. This assembly has an integrated key, so your existing Woodruff Key will no longer be needed.
$137.99
$
Usually ships in 3-7 days
$1.99
$
Usually ships in 3-7 days
Homelite 640213001
Cylinder
$40.99
$
Usually ships in 3-7 days
Homelite 660613003
Cap Screw (M5 x 20 mm, T25 Torx Soc. Hd.)
$1.99
$
Usually ships in 3-7 days
Homelite 698288001
Piston Ring
$4.49
$
In Stock, only 1 left!
Homelite 309120005
Piston
$15.99
$
Usually ships in 3-7 days
Homelite 620719001
Piston Pin
$1.99
$
Usually ships in 0 days
Homelite 678077001
Piston Pin Clip
$1.99
$
Usually ships in 0 days
$1.99
$
Usually ships in 3-7 days
