RTSE200A3 - Generac Power Transfer Switch (SN: 4372559 - 4812198) (2007) 200A Transfer Switch Assembly (0G0351$-J) Parts Diagram

Power Transfer Switch

200A Transfer Switch Assembly (0G0351$-J) Parts Diagram

  • Title

1

Generac 0D9618

TRANSFER SW. HSB 200A 2P 250V

Note: ORDER REPL. PART 0L2911 INTERNAL COMPONENTS ALSO AVAILABLE 0E6154A STANDBY COIL 0E6154 UTILITY COIL LIMIT SWITCH 084464 QTY 2 PLASTIC COVER OVER TRANSFER MECH NEXT TO COILS 0F20780SRV CLIP FOR PLASTIC COVER 0F2078WSRV SPADE CONNECTOR KIT 0G10380SRV WHICH INCLUDES 2 EA OF 0E6032,0E6033, AND 0E6034 0C2237BSRV RETAINING CLIP 0G10010SRV (2) PLUNGERS AND CLIP FOR COILS

$

$

Not available

2

Generac 0E3628

CIRCUIT BREAKER, 200A 2-POLE

$610.99

$

Usually ships in 2-12 days

0

3

Generac 0E3664

BASE CIRCUIT BREAKER 2-POLE

$519.99

$

In Stock, only 1 left!

0

4

Generac 0F9857

BUSBAR 200A HSB XFER SW

$96.99

$

Usually ships in 2-12 days

0

5

Generac 0E3375

LUG SOLDERLESS 250-#6 AL/CU

$29.99

$

Usually ships in 2-12 days

0

6

Generac 0F1252

SCREW BHSC 1/4-20 X 3/8"

$1.49

$

Usually ships in 2-12 days

0

7

Generac 0G3976

SCREW BHSC 1/4-20 X 3/4

$0.99

$

Usually ships in 2-12 days

0

8

Generac 22127

NUT 1/4-20

$

$

Not available

9

Generac 0E6523

GROUND BAR (5) 4-14 AWG CONN

$20.99

$

Usually ships in 2-12 days

0

10

Generac 63617

RELAY PNL 12VDC DPDT

Note: SUPPLIED WITH HARNESS ITEM #39

$

$

Not available

11

Generac 0D2806

FUSEBLOCK 30A 600V 2 POLE

Note: SUPPLIED WITH HARNESS ITEM #39

$40.99

$

Usually ships in 2-12 days

0

12

Generac 073590A

FUSE 5A X BUSS HLDR73591

$8.99

$

In Stock, only 1 left!

0

13

Generac 48850

BLOCK TERM 20A 5 X 6 X 1100V

Note: SUPPLIED WITH HARNESS ITEM #39

$

$

Not available

14

Generac 0A1661

RIVET POP .156 X .67

$0.99

$

Usually ships in 2-12 days

0

15

Generac 0C4449A

ASSY NEUTRAL BLOCK 200A

Note: ORDER 0C4449ASRV

$

$

Not available

16

Generac 90388

SCREW HHTT M6-1.0 X 12 MM

$

$

Not available

17

Generac 0G1018

WELDMENT TRANSFER SWITCH ENCL

$323.99

$

Usually ships in 2-12 days

0

18

Generac 0G1035

COVER INSIDE 200A DUAL BREAKER

$128.99

$

Usually ships in 2-12 days

0

19

Generac 0G1034

COVER TRANSFER SWITCH

$137.99

$

Usually ships in 2-12 days

0

20

Generac 0G0345

DECAL TRANSFER SWITCH RTS SE

$3.99

$

Usually ships in 2-12 days

0

21

0G0136

SUBPLT XFER SW HSB SERV ENT

$

$

Not available

22

0E3477

DECAL DATA

$

$

Not available

0G0351A

DECAL TRANSFER SWITCH DATA 200

$

$

Not available

23

Generac 0E3484

DECAL MANUAL OPERATING HANDLE

$24.99

$

Usually ships in 2-12 days

0

24

Generac 0F9969

DECAL UTILITY DISCONNECT

$3.99

$

Usually ships in 2-12 days

0

25

Generac 0F9970

DECAL GENERATOR DISCONNECT

$

$

Not available

26

Generac 0A9457

DECAL NEUTRAL

$0.99

$

Usually ships in 2-12 days

0

27

Generac 0D3587

DECAL FUSE REPLACEMENT

$0.99

$

Usually ships in 2-12 days

0

28

Generac 0C2262

DECAL TERMINAL STRIP

$1.49

$

Usually ships in 2-12 days

0

29

Generac 0E7109

DECAL TEST SEQUENCE

$2.99

$

Usually ships in 2-12 days

0

30

Generac 63378

HOLDER CABLE TIE (NOT SHOWN)

$

$

Not available

31

Generac 45764

SCREW HHTT M4-.7 X 8 BP

$

$

Not available

32

Generac 49813

NUT HEX M6 X 1.0 G8 YEL CHR

$

$

Not available

33

Generac 97872

SCREW HHTT M6-1.0 X 35 YC

$

$

Not available

34

Generac 0C6748

NUT HEX LOCK M4-0.7 SS NYL INS

$8.99

$

Usually ships in 2-12 days

0

35

Generac 26579

WASHER SHAKEPROOF EXT #8 STEEL

$

$

Not available

36

Generac 0E7213

THUMB SCREW 1/4-20x1/2

$

$

Not available

37

Generac 22473

WASHER FLAT 1/4-M6 ZINC

$

$

Not available

38

Generac 22097

WASHER LOCK M6-1/4

$

$

Not available

39

Generac 0G0111

WIRING HARNESS HSB (NOT SHOWN)

$409.99

$

Usually ships in 2-12 days

0

40

Generac 0E6193

BRACKET ARM EXTENDER

$2.49

$

Usually ships in 2-12 days

0

41

Generac 64526

SCREW HWHS #6-25 X 3/8

$

$

Not available

42

Generac 0E6155

ARM EXTENDER PIN

Note: SUPPLIED WITH TRANSFER SWITCH ITEM #1

$16.99

$

In Stock, only 1 left!

0

43

Generac 0E6033

90 DEGREE DN SPADE CONNECTOR

Note: SUPPLIED WITH TRANSFER SWITCH ITEM #1. USE 0G10380SRV

$

$

Currently unavailable

44

Generac 74908

SCREW HHTT M5-0.8 X 10 BP

$

$

Not available

45

Generac 067210A

DECAL, GROUNDING LUG (NOT SHOWN)

$0.99

$

Usually ships in 2-12 days

0

46

Generac 0E6303

WIRE-A

$2.99

$

Usually ships in 2-12 days

0

47

Generac 0E6303A

WIRE-B

$55.99

$

Usually ships in 2-12 days

0

48

Generac 0E6303B

WIRE-E1

$2.99

$

Usually ships in 2-12 days

0

49

Generac 0G3259

DECAL TERMINAL SHOCK HZD BI

$2.99

$

Usually ships in 2-12 days

0

50

Generac 0G0900

DECAL-UL LIST HSB

$0.99

$

Usually ships in 2-12 days

0

51

Generac 0F9843

RISER CIRCUIT BREAKER

$49.99

$

Usually ships in 2-12 days

0

52

Generac 0F9856

BLOCK PHENOLIC

$184.99

$

Usually ships in 2-12 days

0

53

Generac 0F9851

FUSE BRACKET

$24.99

$

Usually ships in 2-12 days

0

54

Generac 0G3274

DECAL LIVE CIRCUIT ENG/FRN/SPN

$12.99

$

Usually ships in 2-12 days

0

55

Generac 0G0011B

WIRE RED 3/0 E1

$31.99

$

Usually ships in 2-12 days

0

56

Generac 0G0011A

WIRE RED 3/0 E2

$152.99

$

Usually ships in 2-12 days

0

57

Generac 0G0011D

WIRE BLACK 3/0 N1

$43.99

$

Usually ships in 2-12 days

0

58

Generac 0G0011C

WIRE BLACK 3/0 N2

$

$

Not available

59

Generac 43180

WASHER FLAT M4

$

$

Not available

60

Generac 058000E

NUT TRIC 1/4-20 X .525

$12.99

$

Usually ships in 2-12 days

0

61

Generac 0G4106

BLOCK, PHENOLIC/BUSBAR COVER

$57.99

$

Usually ships in 2-12 days

0

62

Generac 0G5479

SCREW BHSC 1/4-20 X 1/2

$0.99

$

Usually ships in 2-12 days

0
