Bad Boy Revolt - Bad Boy Stand-On Mower (2019) PODIUM ASSEMBLY Parts Lookup with Diagrams

1

Bad Boy 013-2050-00

1/4-20 Nylon Insert flange Nut

$1.49

$

In Stock, only 2 left!

2

Bad Boy 013-5019-00

10-24 Nylon Insert Locknut Zinc Orange Nylon

$0.99

$

In Stock, only 2 left!

3

Bad Boy 013-6051-00

3/8" Fine Threaded Jam Nut

$0.99

$

In Stock, Qty 20+

4

Bad Boy 013-8049-00

5/16" Nylon Flange Nut

$0.99

$

In Stock, Qty 17

5

Bad Boy 013-9002-00

5/16" Flange Nut

$0.99

$

In Stock, Qty 10

6

Bad Boy 013-9005-00

5/16-18 Nylock Jam Nut 1/2 Nut

$3.49

$

Usually ships in 4-7 days

7

Bad Boy 018-0024-00

M6-1.0 X 16MM Hex Bolt

$3.49

$

In Stock, Qty 8

8

Bad Boy 018-0056-00

5/16" x 6" Carriage Bolt

$3.49

$

Usually ships in 4-7 days

9

Bad Boy 018-1080-00

12-24x 1/2 HWH Bolt

$2.49

$

Usually ships in 4-7 days

10

Bad Boy 018-2006-00

5/16 x 1 1/4 Hex Bolt

$0.99

$

In Stock, Qty 5

11

Bad Boy 018-5020-00

5/16" x 1 1/2" Carriage Bolt

$0.99

$

Usually ships in 4-7 days

12

Bad Boy 018-5043-00

3/8" x 1 1/4" Carriage Bolt

$1.49

$

In Stock, Qty 10

13

Bad Boy 018-5200-00

10-24 X 5/8 BS Button Head Bolt

$0.99

$

In Stock, Qty 5

14

Bad Boy 018-6049-00

3/8" x 1" Hex Bolt

$0.99

$

In Stock, Qty 13

15

Bad Boy 018-8065-00

5/16" x 1" Carriage Bolt

$0.99

$

In Stock, Qty 7

16

Bad Boy 019-2003-00

.390 x .750 x .062 Nylon Washer

$0.99

$

Usually ships in 4-7 days

17

Bad Boy 019-5029-00

3/8" Flat Washer

$0.99

$

In Stock, Qty 5

18

Bad Boy 019-5037-00

3/8" Lock Washer

$0.99

$

In Stock, Qty 11

19

Bad Boy 019-6042-00

.360 ID Plastic Washer

$0.99

$

In Stock, Qty 11

20

Bad Boy 019-8040-00

1/4" x 3/4" Carriage Bolt

$1.99

$

In Stock, only 3 left!

21

Bad Boy 024-6034-00

1/4" Press in Grease Fitting

$0.99

$

In Stock, only 2 left!

22

Bad Boy 025-2001-00

ACS Spacer 3/4x3/8x1/4

$16.99

$

Usually ships in 4-7 days

23

Bad Boy 026-0098-00

2019 Stand On Battery Hold Down

$18.99

$

Usually ships in 4-7 days

24

Bad Boy 031-0026-00

2019 Stand On Control Arm Stop Weldment

$65.99

$

Usually ships in 4-7 days

25

Bad Boy 031-0027-00

2019 Stand On Control Arm Stop Weldment_rear

$49.99

$

Usually ships in 4-7 days

26

Bad Boy 031-0028-00

2019 Stand On Drive Arm Actuator weldment_right

$45.99

$

Usually ships in 4-7 days

27

Bad Boy 031-0029-00

2019 Stand On Drive Arm Actuator weldment_left

$45.99

$

Usually ships in 4-7 days

28

Bad Boy 031-0032-00

2019 Drive Arm Bushing

$7.99

$

Usually ships in 4-7 days

29

Bad Boy 034-1025-00

Brake Spring

$13.99

$

Usually ships in 4-7 days

30

Bad Boy 035-0006-19

2019 Stand On Drive Push Rod Assembly

$49.99

$

Usually ships in 4-7 days

31

Bad Boy 039-0087-00

2019 Stand On Console Bracket Weldment

$22.99

$

Usually ships in 0 days

32

Bad Boy 042-9000-00

Ignition Key

$4.49

$

In Stock, Qty 20+

33

Bad Boy 054-8017-00

Choke

$27.99

$

In Stock, Qty 20+

34

Bad Boy 055-2012-00

Universal Throttle

$27.99

$

In Stock, only 3 left!

35

Bad Boy 055-2013-00

Throttle Knob

$13.99

$

In Stock, only 3 left!

36

Bad Boy 055-8021-75

Outlaw Throttle Cable

$30.99

$

In Stock, Qty 12

37

Bad Boy 056-8058-00

PTO Switch

$36.99

$

In Stock, Qty 20+

38

Bad Boy 064-3000-00

Brake Cable

$33.99

$

In Stock, Qty 9

39

Bad Boy 064-8060-00

36" Red Battery Cable

$22.99

$

Usually ships in 4-7 days

40

Bad Boy 067-0020-18

Revolt EPA Cannister Assy

$91.99

$

Usually ships in 0 days

41

Bad Boy 067-8090-03

Hydro Tank Assembly

$45.99

$

Usually ships in 4-7 days

42

Bad Boy 068-8051-00

Interstate FAYTX14 Battery

$

Not available 

43

Bad Boy 069-0002-00

8507A13 McMaster Carr Plunger

$90.99

$

Usually ships in 4-7 days

44

Bad Boy 069-2013-00

2019 Stand On Brake Handle

$125.99

$

Usually ships in 4-7 days

45

Bad Boy 069-2014-00

2019 Stand On Control Grip

$8.49

$

Usually ships in 4-7 days

46

Bad Boy 069-7000-00

Rubber Brake Grip-cZT/ZT 2013

$6.99

$

In Stock, only 3 left!

47

Bad Boy 071-6005-00

2019 Stand On Waterbottle Cage

$24.99

$

Usually ships in 4-7 days

48

Bad Boy 077-1000-00

Magnet-Steering Arm-Stand On

$15.99

$

Usually ships in 4-7 days

49

Bad Boy 077-2076-00

USB Port

$49.99

$

In Stock, only 4 left!

50

Bad Boy 077-8073-00

Safety Switch

$11.99

$

In Stock, Qty 20+

51

Bad Boy 077-8076-00

Ignition Switch

$22.99

$

In Stock, Qty 20+

52

Bad Boy 079-4106-00

2019 Podium Panel Right

$39.99

$

Usually ships in 4-7 days

53

Bad Boy 079-4111-00

2019 Podium Panel Left

$39.99

$

Usually ships in 4-7 days

54

Bad Boy 079-4112-00

2019 Stand On Podium Front Panel Weldment

$51.99

$

Usually ships in 4-7 days

55

Bad Boy 083-4013-00

Tachometer

$79.99

$

In Stock, Qty 20+

56

Bad Boy 086-0015-00

Safety Switch Harness

$74.99

$

In Stock, only 2 left!

57

Bad Boy 086-0091-00

2019 Revolt Wiring Harness

$414.99

$

Usually ships in 4-7 days

58

Bad Boy 089-1000-00

Oil Light

$13.99

$

Usually ships in 4-7 days

57.1

Bad Boy 086-1201-00

Relay Terminal

$26.99

$

In Stock, Qty 12

Revolt - Bad Boy Stand-On Mower (2019) PODIUM ASSEMBLY Parts Diagram

PODIUM ASSEMBLY Parts Diagram
