Revolt - Bad Boy 48", 54", 61" Stand-On Mower (2024) TRANSAXLE SUBS Parts Diagram

48", 54", 61" Stand-On Mower

TRANSAXLE SUBS Parts Diagram

  • Title

1

Bad Boy 022-4040-00

23x9-12 Reaper Turf Tire & Wheel Assembly

$341.99

$

Usually ships in 4-7 days

0

2

Bad Boy 022-3011-00

12x7" Black Wheel

$125.99

$

Usually ships in 4-7 days

0

3

Bad Boy 022-4035-00

23x9-12 Reaper Turf Tire Only

$196.99

$

In Stock, only 3 left!

0

4

Bad Boy 022-4200-00

23x11-12 Reaper Turf Assembly

$331.99

$

In Stock, only 2 left!

0

5

Bad Boy 022-4070-00

12x8.5 Black Wheel

$150.99

$

Usually ships in 4-7 days

0

6

Bad Boy 022-4195-00

Tire, 23/11x12 Reaper Turf

$257.99

$

In Stock, Qty 5

0

7

Bad Boy 035-0006-19

2019 Revolt Push Rod Assembly

$49.99

$

Usually ships in 4-7 days

0

8

Bad Boy 013-6050-00

5/16 LH Nut

$4.99

$

Usually ships in 4-7 days

0

9

Bad Boy 013-6051-00

3/8-24 HEX NUT ZINC YELLOW

$0.99

$

In Stock, Qty 20+

0

10

Bad Boy 031-0092-00

2019 Revolt Push Rod

$22.99

$

Usually ships in 0 days

0

11

Bad Boy 035-0006-00

2019 Renegade Push Rod Adjuster

$

$

Currently unavailable

12

Bad Boy 048-3000-00

Spherical Rod End - Outlaw

$15.99

$

Usually ships in 4-7 days

0

13

Bad Boy 048-3002-00

Spherical Rod End - Outlaw

$34.99

$

Usually ships in 4-7 days

0
