Renegade Diesel - Bad Boy Zero-Turn Mower (2025) Drive Arms Parts Diagram

The Renegade Diesel Zero Turn Mower delivers exceptional power with a 24.7 hp Perkins diesel engine, a heavy-duty 61" fabricated steel deck, and patented 3-Link rear and independent front suspension for a smooth ride. Built for professionals or la

Drive Arms Parts Diagram

  • Title

1

Bad Boy 013-0021-00

Extruded Nut 3/8"-16 3/4" Hole Center With Patch

$4.99

$

In Stock, Qty 6

0

2

Bad Boy 013-8043-00

5/16-18 HEX NUT ZINC

$0.99

$

In Stock, Qty 5

0

3

Bad Boy 013-8047-00

5/16-18 NYL INS L/N ZC

$0.99

$

In Stock, only 4 left!

0

4

Bad Boy 013-8050-00

1/2-13 NYLON INSERT FLANGE LOCKNUT ZINC

$1.99

$

In Stock, Qty 20+

0

5

Bad Boy 013-9002-00

5/16-18 HEX SERRATED FLANGE NUT HARD/ZINC

$0.99

$

In Stock, Qty 10

0

6

Bad Boy 018-0078-00

3/8-16 X 1 1/4 HEX WASHER UNSLOT MACHINE SCREW ZINC GR5

$1.99

$

Usually ships in 4-7 days

0

7

Bad Boy 018-1080-00

12-24 X 1/2 HEX WASHER UNLSOT F TCS ZINC

$2.49

$

Usually ships in 4-7 days

0

8

Bad Boy 018-2006-00

5/16-18 X 1-1/4 HEX C/S (GR.5) ZC

$0.99

$

In Stock, Qty 5

0

9

Bad Boy 018-5040-00

3/8-16 X 1-1/4 HEX CAP SCREW (GR.5) ZINC

$0.99

$

In Stock, Qty 17

0

10

Bad Boy 019-5037-00

3/8 SPLIT LOCKWASHER ZINC

$0.99

$

In Stock, Qty 8

0

11

Bad Boy 019-8051-00

5/16 SPLIT LOCKWASHER ZINC

$0.99

$

In Stock, only 4 left!

0

12

Bad Boy 028-0051-00

2019 Steering Actuator Rod

$24.99

$

Usually ships in 4-7 days

0

13

Bad Boy 031-0030-24

R Series Square Drive Arm Actuator RH Assembly

$102.99

$

Usually ships in 4-7 days

0

14

Bad Boy 031-0031-24

R Series Square Drive Arm Actuator LH Assembly

$102.99

$

Usually ships in 4-7 days

0

15

Bad Boy 031-9070-00

R Series Square Drive Arm RH Assembly

$148.99

$

Usually ships in 4-7 days

0

16

Bad Boy 031-9071-00

R Series Square Drive Arm LH Assembly

$148.99

$

Usually ships in 4-7 days

0

17

Bad Boy 032-0002-00

Snap-in Drive Arm Bushing

$16.99

$

In Stock, only 2 left!

0

18

Bad Boy 035-0005-00

2019 Renegade Push Rod Assembly

$49.99

$

In Stock, only 4 left!

0

19

Bad Boy 039-2163-00

Push In Arm Safety Switch R Series Bracket

$

$

Currently unavailable

20

Bad Boy 057-5800-00

Speed Limiting Knob 3/8-16X 3"

$6.99

$

Usually ships in 4-7 days

0

21

Bad Boy 070-5376-22

2022 Horizontal Diesel Frame

$

$

Not available

22

Bad Boy 077-8075-00

Rail Mount Safety Switch

$6.99

$

Usually ships in 4-7 days

0

23

Bad Boy 087-0002-00

2019 SROID Damper With Spherical Rod Ends

$66.99

$

Usually ships in 4-7 days

0

24

Bad Boy 091-1114-00

2018 LH/RH Steering Control Decal Roll

$16.99

$

Usually ships in 4-7 days

0
