Renegade Diesel - Bad Boy Zero-Turn Mower (2024) FLOORBOARD & RADIATOR Parts Diagram

Zero-Turn Mower

FLOORBOARD & RADIATOR Parts Diagram

  • Title
1

Bad Boy 013-8039-00

1/4-20 HEX NUT ZINC

$0.99

$

Usually ships in 4-7 days

0

2

Bad Boy 014-3005-00

Electric Fan for 2019 Diesel Radiator

$797.99

$

Usually ships in 4-7 days

0

3

Bad Boy 015-0098-00

1/4 NPT Drain Plug

$9.49

$

Usually ships in 4-7 days

0

4

Bad Boy 015-0104-00

radiator cap

$33.99

$

Usually ships in 4-7 days

0

5

Bad Boy 019-4008-00

1/4SPLIT LOCKWASHER ZINC

$0.99

$

In Stock, Qty 6

0

6

Bad Boy 019-8040-00

1/4-20 X 3/4 CARRIAGE BOLT (GR.5) ZINC

$1.99

$

In Stock, only 3 left!

0

7

Bad Boy 024-0015-00

1/4 Barb to 3/16 NPT Overflow Fitting

$

$

Currently unavailable

8

Bad Boy 026-2008-00

Screen Rentention Plate for 2019 Diesel Radiator

$

$

Not available

9

Bad Boy 030-0090-00

1/4-20 x 3/4 Thumb Screw

$7.99

$

Usually ships in 4-7 days

0

10

Bad Boy 079-3156-00

2024 R-Series Floorboard

$

$

Currently unavailable

11

Bad Boy 081-2024-00

2024 R-Series Floor Mat

$

$

Not available
