Renegade Diesel - Bad Boy Zero-Turn Mower (2020) REAR COVER & HYDRAULIC COOLERS Parts Diagram

Zero-Turn Mower

REAR COVER & HYDRAULIC COOLERS Parts Diagram

  • Title

7

Bad Boy 013-2050-00

1/4-20 Hex flang lock nut

$1.49

$

In Stock, only 2 left!

0

11

Bad Boy 013-5202-00

3/8-16 NYLON INSERT FLANGE LOCKNUT (GR.F) ZINC

$1.99

$

In Stock, Qty 20+

0

19

Bad Boy 013-8050-00

1/2-13 NYLON INSERT FLANGE LOCKNUT ZINC

$1.99

$

In Stock, Qty 20+

0

20

Bad Boy 013-8051-00

1/4" Wing Nut

$0.99

$

In Stock, Qty 5

0

30

Bad Boy 014-5063-00

2019 Horizontal Battery Hold Down Cover

$11.99

$

Usually ships in 4-7 days

0

51

Bad Boy 018-0040-00

1/2" x 8 1/2 GR 5 Hex Bolt

$7.49

$

In Stock, Qty 15

0

53

Bad Boy 018-0044-00

3/8" x 2 1/2" Carriage Bolt

$3.49

$

Usually ships in 4-7 days

0

76

Bad Boy 018-4702-00

1/4-20 x 1-1/4 GR 5 Hex Bolt

$0.99

$

Usually ships in 4-7 days

0

95

Bad Boy 018-8051-00

1/4" x 1" Carriage Bolt

$1.99

$

Usually ships in 4-7 days

0

96

Bad Boy 018-8052-00

1/4" x 3/4" Hex Bolt

$0.99

$

In Stock, only 3 left!

0

110

Bad Boy 019-7040-00

1/4" Flat Washer

$0.99

$

In Stock, Qty 7

0

131

Bad Boy 025-0028-00

2019 Pulley Spacer .75 x .5 x 4.375

$9.99

$

In Stock, only 2 left!

0

135

Bad Boy 025-5203-00

Spacer 3/4 OD x 1/2 ID x 3\4 Length

$3.49

$

In Stock, Qty 15

0

139

Bad Boy 026-2224-00

2019 Horizontal Suspension Rear Cover

$193.99

$

Usually ships in 4-7 days

0

151

Bad Boy 029-7038-00

8" Rubber Bumper

$30.99

$

Usually ships in 4-7 days

0

171

Bad Boy 033-7027-00

2019 Outlaw Horizontal Rear V Pulley

$49.99

$

In Stock, Qty 5

0

213

Bad Boy 064-4000-00

Red Battery Cable - Diesel

$25.99

$

Usually ships in 4-7 days

0

214

Bad Boy 064-4001-00

Black Battery Cable - Diesel

$23.99

$

Usually ships in 4-7 days

0

219

Bad Boy 067-8052-19

Renegade Oil Cooler Assembly

$75.99

$

Usually ships in 4-7 days

0

224

Bad Boy 068-8050-00

Battery - Diesel/Renegade Models PF-516

$

$

Not available

231

Bad Boy 070-5374-19

2019 Horizontal Diesel Frame

$

$

Currently unavailable

219.1

Bad Boy 067-8052-00

2019 12" Oil Cooler With Fittings

$66.99

$

Usually ships in 4-7 days

0

219.2

Bad Boy 051-8063-14

3/8" Clear Hose

$6.49

$

Usually ships in 4-7 days

0

219.3

Bad Boy 051-8063-24

3/8" Clear Hose

$13.99

$

Usually ships in 4-7 days

0

219.4

Bad Boy 072-8065-00

3/8" Hose Clamp

$1.49

$

In Stock, only 2 left!

0
