Rebel - Bad Boy Zero-Turn Mower (2020) COVERS & SEAT PAN ASSEMBLY Parts Diagram

Zero-Turn Mower

COVERS & SEAT PAN ASSEMBLY Parts Diagram

  • Title

2

Bad Boy 013-0005-00

1/2" Center Lock Nut

$3.49

$

Usually ships in 4-7 days

0

4

Bad Boy 013-0054-00

1/4-20 Cage Nut

$0.99

$

Usually ships in 4-7 days

0

6

Bad Boy 013-2050-00

1/4-20 Nylon Insert flange Nut

$1.49

$

In Stock, only 2 left!

0

9

Bad Boy 013-5202-00

3/8" Nylock Flange Nut

$1.99

$

In Stock, Qty 20+

0

14

Bad Boy 013-8049-00

5/16" Nylon Flange Nut

$0.99

$

In Stock, Qty 17

0

17

Bad Boy 013-9002-00

5/16" Flange Nut

$0.99

$

In Stock, Qty 10

0

19

Bad Boy 013-9005-00

5/16-18 Nylock Jam Nut 1/2 Nut

$3.49

$

Usually ships in 4-7 days

0

22

Bad Boy 014-9003-00

1 1/2 x 3 Frame Plug

$3.49

$

Usually ships in 4-7 days

0

42

Bad Boy 018-0024-00

M6-1.0 X 16MM Hex Bolt

$3.49

$

In Stock, Qty 8

0

45

Bad Boy 018-0044-00

3/8" x 2 1/2" Carriage Bolt

$3.49

$

Usually ships in 4-7 days

0

46

Bad Boy 018-0050-00

1/2-13 X 3.25 Hex Bolt - Grade 5

$0.99

$

Usually ships in 4-7 days

0

51

Bad Boy 018-2007-00

5/16" x 1" Bolt

$0.99

$

In Stock, only 2 left!

0

62

Bad Boy 018-4703-00

5/16" x 1 1/4" Carriage Bolt

$0.99

$

In Stock, only 3 left!

0

66

Bad Boy 018-5044-00

3/8" x 1" Carriage Bolt

$0.99

$

Usually ships in 4-7 days

0

72

Bad Boy 018-8052-00

1/4" x 3/4" Hex Bolt

$0.99

$

In Stock, only 3 left!

0

73

Bad Boy 018-8065-00

5/16" x 1" Carriage Bolt

$0.99

$

In Stock, Qty 7

0

79

Bad Boy 019-6042-00

.360 ID Plastic Washer

$0.99

$

In Stock, Qty 11

0

80

Bad Boy 019-8040-00

1/4" x 3/4" Carriage Bolt

$1.99

$

In Stock, only 3 left!

0

95

Bad Boy 026-2019-00

2019 Outlaw Seat Plate

$105.99

$

Usually ships in 4-7 days

0

96

Bad Boy 026-2219-00

2019 Rebel Rear Cover Side Plate

$193.99

$

Usually ships in 4-7 days

0

97

Bad Boy 026-2221-00

2019 Vertical Rear Cover Tailgate Plate

$257.99

$

Usually ships in 4-7 days

0

98

Bad Boy 026-2230-00

2019 Outlaw Adjustable Foot Plate

$75.99

$

Usually ships in 4-7 days

0

105

Bad Boy 028-0090-00

Seat Latch Rod Assembly

$41.99

$

Usually ships in 4-7 days

0

108

Bad Boy 029-4010-00

Button Bumper

$1.49

$

Usually ships in 4-7 days

0

109

Bad Boy 029-8000-00

2017 XP Bumper

$33.99

$

In Stock, only 2 left!

0

111

Bad Boy 030-3050-00

#10 x 1/2" Self Tapping Screw

$0.99

$

In Stock, Qty 9

0

113

Bad Boy 030-7040-00

1/4 x 1 Hex Head Tek screw

$1.49

$

Usually ships in 4-7 days

0

120

Bad Boy 032-0001-00

2019 Bad Boy X Cylindrical Seat Mount

$24.99

$

Usually ships in 4-7 days

0

124

Bad Boy 034-1025-00

Brake Spring

$13.99

$

Usually ships in 4-7 days

0

130

Bad Boy 040-6080-00

Ratchet Fastener

$3.49

$

In Stock, only 3 left!

0

155

Bad Boy 064-8081-00

Seat Cable

$16.99

$

In Stock, only 2 left!

0

156

Bad Boy 067-0020-19

2019 Outlaw EPA Cannister Assembly

$50.99

$

Usually ships in 4-7 days

0

165

Bad Boy 070-5371-19

2019 Rigid Frame

$

$

Not available

166

Bad Boy 071-5060-18

2019 Rebel Seat

$683.99

$

Usually ships in 4-7 days

0

167

Bad Boy 071-5065-00

2019 Renegade Seat

$1025.99

$

Usually ships in 4-7 days

0

171

Bad Boy 079-3155-00

2019 Outlaw Floorboard

$125.99

$

Usually ships in 4-7 days

0

173

Bad Boy 081-0050-00

OUTLAW2019_FLOORMAT

$83.99

$

Usually ships in 4-7 days

0

174

Bad Boy 081-0051-00

FLOORMAT_OUTLAW_2019

$83.99

$

Usually ships in 4-7 days

0

182

Bad Boy 089-0006-00

2019 2X2 Folding ROPS

$497.99

$

Usually ships in 4-7 days

0
