Ram 50 KZ (965882801) - Dixon 50" Ram Zero-Turn Mower (2008-12) BRAKE / REAR MOWER LIFT Parts Diagram

50" Ram Zero-Turn Mower

BRAKE / REAR MOWER LIFT Parts Diagram

  • Title
1

Dixon 510030701

SPRING, COMPRESSION

$

$

Not available

2

Dixon 510207201

GRIP, HANDLE, BLACK

$6.99

$

In Stock, only 4 left!

0

3

Dixon 510422901

ROD, HANDLE RELEASE

$

$

Not available

4

Dixon 516008801

ROD, LATCH RELEASE
(Superseded to 583629301)

$6.49

$

In Stock, only 1 left!

0

5

Dixon 522710802

SHAFT.ASSY.BRAKE.WLDMT.BLACK

$241.99

$

Usually ships in 3-10 days

0

6

Dixon 522823602

SHAFT, LIFT, BLK
(Superseded to 574216602)

$

$

Not available

7

Dixon 510207301

BUTTON, PUSH, BLACK (2 2)

$5.99

$

In Stock, only 1 left!

0

8

Dixon 510185301

LINK, REAR SUSPENSION
(Superseded to 587623001)

$12.99

$

In Stock, only 1 left!

0

9

Dixon 522858601

ASSEMBLY, BRKT LINK
(Superseded to 587623001)

$12.99

$

In Stock, only 1 left!

0

10

Dixon 539101341

HCS 3/8C X 3

$5.99

$

In Stock, Qty 12

0

11

Dixon 532175994

NUT, LIFT LINK 7/16-20
(Superseded to 589464902)

$4.99

$

In Stock, Qty 5

0

12

Dixon 532195185

ARM.SUSPENSION.MOWER
(Superseded to 531169201)

$14.99

$

In Stock, Qty 5

0

13

Dixon 532195161

STUD.FASTNER.W/ANTI-ROTATE

$

$

Not available

14

Dixon 539113621

SB 3/8-16 X 3/8 SKT HD ZD
(Superseded to 596241101)

$3.99

$

Usually ships in 3-10 days

0

15

Dixon 539990598

WASHER 1/4 FLAT

$

$

Not available

16

Dixon 539976978

NUT 1/4-20 NYLOC
(Superseded to 582478602)

$2.49

$

In Stock, Qty 20+

0

17

Dixon 510184901

PLASTIC NUT

$6.49

$

In Stock, only 3 left!

0

18

Dixon 539105069

E-RING 5/8

$3.99

$

Usually ships in 3-10 days

0

19

Dixon 539112899

5/16-18 NYLOC FLANGE NUT
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

20

$

$

Not available

21

$12.99

$

In Stock, only 2 left!

0

22

Dixon 510184802

BRAKE, RT, BLACK

Note: RT

$47.99

$

Usually ships in 3-10 days

0

23

Dixon 510184702

BRAKE, LT, BLACK

Note: LT

$47.99

$

Usually ships in 3-10 days

0

24

Dixon 510207401

ROD, THRD, 3/8-24

$9.99

$

Usually ships in 3-10 days

0

25

Dixon 539977703

CLEVIS PIN 3/8 X 1 1/8

$5.99

$

In Stock, Qty 11

0

26

Dixon 539990365

COTTER PIN 1/8 X 3/4
(Superseded to 876020412)

$6.49

$

In Stock, Qty 20+

0

27

Dixon 539990155

NUT 3/8F

$4.99

$

In Stock, Qty 16

0

28

Dixon 510207501

YOKE, 3/8 SHORT

$3.99

$

Usually ships in 3-10 days

0

29

Dixon 539990122

WASHER 3/8 SAE FLAT
(Superseded to 596565301)

$3.99

$

In Stock, Qty 20+

0

30

Dixon 539200282

NUT HEX 3/8-16 NYLON, THIN
(Superseded to 596230801)

$3.99

$

In Stock, Qty 15

0
