R5001 - Snapper Rear-Tine Tiller, 5hp 59670: Left Frame Components Parts Diagram

Rear-Tine Tiller, 5hp

59670: Left Frame Components Parts Diagram

  • Title

1

Snapper 7035021

FRAME, Left Side

$

$

Not available

2

Snapper 7018563

GASKET

$

$

Not available

3

Snapper 7090303

NUT, 1/4-28 Hex Top Lock
(Superseded to 703972)

$3.49

$

In Stock, Qty 7

0

4

Snapper 7036038

COVER

$

$

Currently unavailable

5

Snapper 7090819

NUT, 1/2-20 Hex Jam Center Lock
(Superseded to 7090819YP)

$3.49

$

In Stock, only 1 left!

0

6

Snapper 7032260

RETAINER, Boot

$

$

Currently unavailable

7

Snapper 7090822

SCREW, #10-32 x 1/4" Hex Washer (slotted) Self-Tap

$4.49

$

In Stock, Qty 20+

0

8

Snapper 7018569

SEAL, Short
(Superseded to 7075115YP)

$10.99

$

In Stock, Qty 20+

0

9

Snapper 7014673

WASHER, Thrust
(Superseded to 7014673YP)

$3.99

$

In Stock, only 1 left!

0

10

Snapper 7010988

WASHER, Plastic
(Superseded to 7010988YP)

$4.49

$

In Stock, Qty 20+

0

11

Snapper 7051365

ASSEMBLY, Tube Drive
(Superseded to 7051365YP)

$76.99

$

Usually ships in 2-12 days

0

11

Snapper 7051578

ASSEMBLY, Tube Drive

Note: (P/N 59670)

$

$

Not available

12

Snapper 7047852

WELDMENT, Axle
(Superseded to 7047852YP)

Note: (For models RT5, RT8, RT8S)

$66.99

$

Usually ships in 2-12 days

0

12A

Snapper 7051459

AXLE REPLACEMENT
(Superseded to 7051459YP)

Note: (R8000 Models). (Includes 2 40434 hubs and 1 item 13)

$313.99

$

Usually ships in 2-12 days

0

12B

Snapper 7051458

AXLE REPLACEMENT
(Superseded to 7051458YP)

Note: (R5000 Models)

$302.99

$

Usually ships in 2-12 days

0

12C

Snapper 7057399

ASSEMBLY, Axle & Gear

Note: (For models RT5, RT8 & RT8S)

$

$

Currently unavailable

13

Snapper 7011071

WASHER, Thrust
(Superseded to 7011071YP)

$3.99

$

In Stock, Qty 20+

0

14A

Snapper 7051378

GEAR ASS'Y, Cluster
(Superseded to 7051378YP)

Note: (Consists of items 15,16,17 & 18)

$119.99

$

Usually ships in 2-12 days

0

14B

Snapper 7057400

GEAR ASS'Y, Cluster
(Superseded to 7057400YP)

Note: (Consists of items 15B & 16B)

$268.99

$

Usually ships in 2-12 days

0

15A

Snapper 7021868

GEAR, 16 Tooth/10 P Hex
(Superseded to 7021868YP)

$16.99

$

Usually ships in 2-12 days

0

15B

Snapper 7051578

GEAR, 15 Tooth/10 P Hex

Note: Was 21967

$

$

Not available

16A

Snapper 7018564

GEAR, 63 Tooth
(Superseded to 7018564YP)

$46.99

$

Usually ships in 2-12 days

0

16B

Snapper 7018761

GEAR, 64 Tooth
(Superseded to 7018761YP)

$59.99

$

Usually ships in 2-12 days

0

17

Snapper 7021872

TUBE, Hex
(Superseded to 7021872YP)

$8.49

$

Usually ships in 2-12 days

0

18

Snapper 7014369

BEARING
(Superseded to 7014369YP)

$3.99

$

Usually ships in 2-12 days

0

19

Snapper 7021870

SHAFT
(Superseded to 7021870YP)

$6.99

$

Usually ships in 2-12 days

0

20

Snapper 7014331

SPACER

$

$

Not available

21

Snapper 7014330

BEARING, Axle .75" ID x 1.626"/1.75" OD x 1.06" Long
(Superseded to 7014330YP)

$9.99

$

Usually ships in 2-12 days

0

22

Snapper 7090099

SCREW, 1/4-28 x 1/2" Hex Head Cap, Grade 5

$

$

Not available

23

Snapper 7091122

SCREW, 1/4-20 x 1/2" Hex Washer Self-Tap
(Superseded to 7091122SM)

Note: Was 90539

$3.99

$

In Stock, Qty 9

0

24

Snapper 7090821

SCREW, 1/2-20 x 1-7/8" Hex Head Cap, Grade 5

$

$

Currently unavailable

25

Snapper 7011024

PLUG, 3/4"
(Superseded to 7011024YP)

$2.99

$

In Stock, Qty 20+

0

26

Snapper 7021968

SHAFT, Axle

Note: (P/N 59670)

$

$

Not available

27

Snapper 7019738

GEAR- 64 Tooth

Note: (P/N 59670)

$

$

Not available

28

Snapper 7010410

PIN, Groove

Note: (P/N 59670)

$2.99

$

Usually ships in 2-12 days

0

Snapper 7059670

Left Frame Components

$

$

Currently unavailable
