QT02524KNNNA - Generac 25kW Home Standby Generator (SN: 8141109 - 10017929) (2015) Ev Enclosure C2 2.4l G2 Turbo (0J8688) Parts Diagram

25kW Home Standby Generator

Ev Enclosure C2 2.4l G2 Turbo (0J8688) Parts Diagram

  • Title

1

0G80180AL0R

REAR WRAP C2 G2 60KW

Note: SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR), MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM., CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).

$

$

Not available

2

Generac 0C2454

SCREW THF M6-1 X 16 N WA Z/JS

Note: PANELS THAT FASTEN TO THE BASEFRAME (EXCEPT ITEM 1) MUST BE SECURED USING I/N 2 & 5 (THREAD FORMING FASTENERS) AND I/N 10 (LOCK NUT). LOCK NUT IS TO BE INSTALLED AFTER THREAD FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN ENCLOSURE PANELS. ALL PANEL TO PANEL CONNECTIONS TO INCLUDE AT LEAST ONE CONNECTION POINT USING I/N 5 (THREAD FORMING FASTENER).

$3.49

$

Usually ships in 2-12 days

0

3

0F58490AL0R

DOOR C2

Note: SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR), MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM., CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).

$

$

Not available

4

Generac 087233

RIVET POP.1875 X .450 SS

$

$

Not available

5

Generac 0E3257

SCREW TH-FRM M6 W/CAP SHKPRF W

Note: PANELS THAT FASTEN TO THE BASEFRAME (EXCEPT ITEM 1) MUST BE SECURED USING I/N 2 & 5 (THREAD FORMING FASTENERS) AND I/N 10 (LOCK NUT). LOCK NUT IS TO BE INSTALLED AFTER THREAD FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN ENCLOSURE PANELS. ALL PANEL TO PANEL CONNECTIONS TO INCLUDE AT LEAST ONE CONNECTION POINT USING I/N 5 (THREAD FORMING FASTENER).

$5.49

$

Usually ships in 2-12 days

0

6

0F58520AL0R

DUCT DSCHRG LH&RH

Note: SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR), MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM., CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).

$

$

Not available

7

0F98330AL0R

FRONT CORNERS C2

Note: SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR), MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM., CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).

$

$

Not available

8

0F58510AL0R

DUCT DISCHARGE C2

Note: SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR), MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM., CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).

$

$

Not available

9

Generac 049813

NUT HEX M6X1.0 G8 YELCHR
(Superseded to G049813)

$3.49

$

In Stock, only 4 left!

0

10

Generac 077992

NUT HEX LOCK M6-1.0 SS NY INS
(Superseded to G077992)

Note: PANELS THAT FASTEN TO THE BASEFRAME (EXCEPT ITEM 1) MUST BE SECURED USING I/N 2 & 5 (THREAD FORMING FASTENERS) AND I/N 10 (LOCK NUT). LOCK NUT IS TO BE INSTALLED AFTER THREAD FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN ENCLOSURE PANELS. ALL PANEL TO PANEL CONNECTIONS TO INCLUDE AT LEAST ONE CONNECTION POINT USING I/N 5 (THREAD FORMING FASTENER).

$1.49

$

Usually ships in 2-12 days

0

11

0F98350AL0R

ROOF C2

Note: SHEET METAL PARTS LISTED IN THE BOM TABLE ARE REPRESENTING GENERIC PARTS (NO COLOR), MANUFACTURING: FOR CORRECT MATERIAL AND COLOR REFER TO AS400 BOM., CUSTOMER: WHEN ORDERING REPLACEMENT PARTS ENTER BASE NUMBER (FIRST 6 DIGITS ONLY) IN THE SYSTEM FOR CORRECT MATERIAL AND COLOR (FOR REFERENCE SEE GUIDELINE 0H7169).

$

$

Not available

12

Generac 0F2786

SLITTER C4

$220.99

$

Usually ships in 2-12 days

0

13

Generac 0F2785

SPLITTER LOWER C4

$183.99

$

Usually ships in 2-12 days

0

14

Generac 0F3364

SPLITTER STINGER C2

$41.99

$

Usually ships in 2-12 days

0

15

Generac 0F4880

SUPPORT SPLITTER LHC2

$29.99

$

Usually ships in 2-12 days

0

16

Generac 0F5049B

PULL TAB DOOR LOCK SS

$11.99

$

Usually ships in 2-12 days

0

17

Generac 0F4487A

ASSEMBLY COVER ACCESS

Note: CUSTOMER ORDER P/N 0F4487ASRV.

$

$

Not available

18

Generac 022473

WASHER FLAT 1/4-M6 ZINC
(Superseded to G022473)

$2.99

$

In Stock, only 2 left!

0

19

Generac 022097

WASHER LOCK M6-1/4
(Superseded to G022097)

$2.99

$

In Stock, only 1 left!

0

20

Generac 022127

NUT HEX 1/4-20 STEEL
(Superseded to G022127)

$4.99

$

In Stock, Qty 10

0

21

Generac 0F3072

INSULATION RETAINMENT HANGER

$0.99

$

Usually ships in 2-12 days

0

22

Generac 078115

WASHER SELF LOCKING DOME #4-40

$

$

Not available

23

Generac 0C8566

SCREW HHFC M6-1.0X20 G8.8

Note: ON MODELS 4858-0, 4857-0 AND 4806-0 USE 0C8563

$9.49

$

Usually ships in 2-12 days

0

24

0G6001A

KIT INSULATION C2

$

$

Not available

24A

Generac 0G5892

INSULATION DOOR C2

$211.99

$

Usually ships in 2-12 days

0

24B

0L3103

KIT INSULATION C2

$

$

Not available

24BA

Generac 0G5892A

INSULATION ROOF TOP

$223.99

$

Usually ships in 2-12 days

0

24BB

Generac 0G5892F

INSULATION ROOF TOP

$21.99

$

Usually ships in 2-12 days

0

24C

Generac 0G5892C

INSULATION SPLITTER

$41.99

$

Usually ships in 2-12 days

0

24D

Generac 0G5892D

INSULATION SPLITTER

$24.99

$

Usually ships in 2-12 days

0

24E

Generac 0G5892E

INSULATION LOWER SPLITTER

$46.99

$

Usually ships in 2-12 days

0

25

Generac 0F5048D

VISE-ACTION LATCH SLOTTED CIR

Note: FOR KEY ORDER 0F8869D

$31.99

$

Usually ships in 2-12 days

0

26

Generac 0E5968

GASKET EXTRUDED TRIM (328" LG)

Note: THIS IS SOLD BY THE FOOT. IF ORDERING FOR ROOF ORDER 11FT

$3.99

$

Usually ships in 2-12 days

0

27

Generac 0H0412

NUT UM6-1.0 GEOMET

$1.99

$

Usually ships in 2-12 days

0

28

Generac 0H1208A

RF COVER PLATE-PLASTIC-BISQUE

$5.49

$

Usually ships in 2-12 days

0

Generac 0H1208B

RF COVER PLATE-PLASTIC-GREY

$5.49

$

Usually ships in 2-12 days

0

29

Generac 0F4051C

INSULATION DUCT

$94.99

$

Usually ships in 2-12 days

0

30

Generac 0F3890B

RETAINER INSULATION (820)

$18.99

$

Usually ships in 2-12 days

0

31

Generac 0F4051B

INSULATION DUCT SIDES

$55.99

$

Usually ships in 2-12 days

0

32

Generac 0F3890

RETAINER INSULATION (450)

$10.99

$

Usually ships in 2-12 days

0

33

Generac 078115A

WASHER SELF LOCKING DOME #8-32

$2.49

$

Usually ships in 2-12 days

0

34

Generac 0E5298L

FOAM 300 X 300 THERMAL ACO

$18.99

$

Usually ships in 2-12 days

0

35

Generac 042568

SCREW HHC M6-1.0X20 G8.8

$

$

Not available

36

Generac 0912970090

ASSY WIRE 14AWG GRN/YEL

$

$

Not available

37

Generac 022447

WASHER SHAKEPROOF INT 1/4

$

$

Not available

38

Generac 0G9473

DEFLECTOR INTAKE 2.4L G2 TURBO

$266.99

$

Usually ships in 2-12 days

0

39

Generac 0F8869D

KEY VISE-ACTION LATCH SLOT CIR

$11.99

$

In Stock, only 1 left!

0

40

Generac 052250

TAPE FOAM 1X1 (71.0"LG)

$

$

Not available

41

Generac 066760

STRIP SEALANT 1/8X 1 (44.52"LG)
(Superseded to G066760)

$1.99

$

Usually ships in 2-12 days

0
