PZ 6029 PFX (966062201) - Husqvarna 60" Zero-Turn Mower (2009-09) Ignition System Parts Diagram

60" Zero-Turn Mower

Ignition System Parts Diagram

  • Title

1

Husqvarna 574234202

FENDER, LP RT

$218.99

$

Usually ships in 3-10 days

0

2

Husqvarna 574234302

FENDER, LP LT

$218.99

$

Usually ships in 3-10 days

0

3

Husqvarna 510083002

MOUNT, TANK RR

$60.99

$

Usually ships in 3-10 days

0

4

Husqvarna 574291502

SUPPORT, LP FENDER RT

$

$

Not available

Husqvarna 574291802

SUPPORT, LP FENDER LT

$

$

Not available

5

Husqvarna 539990546

NUT 3/8-16 HEX CNTRLK

$

$

Not available

6

Husqvarna 539108271

HCS 3/8-16 x 3½

$5.99

$

In Stock, Qty 8

0

7

Husqvarna 539990613

NUT 3/8-16 HEX WHIZLK

$3.99

$

Usually ships in 3-10 days

0

8

Husqvarna 539990645

BOLT 3/8-16 x 1 RD HD

$

$

Not available

9

Husqvarna 521996501

NUT 3/8-16 HEX FLG NYLOC

$

$

Not available

10

Husqvarna 574291401

BRACKET, LP TANK

$145.99

$

Usually ships in 3-10 days

0

11

Husqvarna 539113226

BOLT 5/16-18 x 1 THD FRM
(Superseded to 593337201)

$3.99

$

Usually ships in 3-10 days

0

12

Husqvarna 539112899

NUT 5/16-18 HEX FLG NYLOC
(Superseded to 594944401)

$6.99

$

In Stock, Qty 20+

0

13

Husqvarna 539110433

GROMMET, FUEL LINE

$4.99

$

Usually ships in 3-10 days

0

14

Husqvarna 539109867

CLAMP, DOUBLE TUBE

$6.99

$

Usually ships in 3-10 days

0

15

Husqvarna 525464701

SCREW 5/16-18 x ¾ HEX FLG

$3.99

$

In Stock, only 1 left!

0

16

Husqvarna 574304901

TOGGLE ASSY

$42.99

$

In Stock, only 1 left!

0

17

Husqvarna 574262403

DASH, LP

$103.99

$

Usually ships in 3-10 days

0

18

Husqvarna 574235002

BRACKET, REGULATOR

$

$

Not available

19

Husqvarna 539976978

NUT ¼-20 HEX NYLOC
(Superseded to 582478602)

$2.49

$

In Stock, Qty 20+

0

20

Husqvarna 539990598

WASHER ¼ FLAT

$

$

Not available

21

Husqvarna 539990548

BOLT ¼-20 x 1 HEX HD

$3.99

$

In Stock, only 1 left!

0

22

Husqvarna 539102685

CLIP

$4.99

$

Usually ships in 3-10 days

0

23

Husqvarna 539107475

BOLT 5/16-18 x ¾ THD FRM

$6.49

$

In Stock, only 4 left!

0

24

Husqvarna 574514001

TIMER, SEAT

$120.99

$

In Stock, only 1 left!

0

25

Husqvarna 574233903

COVER, LP DASH

$36.99

$

Usually ships in 3-10 days

0

26

Husqvarna 573978901

DECAL, LP CONTROL

$

$

Not available

27

Husqvarna 539104763

RETAINER, U TYPE

$6.49

$

In Stock, Qty 12

0

28

Husqvarna 539110074

HOUR METER
(Superseded to 576179401)

$34.99

$

In Stock, Qty 6

0

29

Husqvarna 574455401

SWITCH, IGNITION

$34.99

$

In Stock, only 1 left!

0

30

Husqvarna 539131627

SWITCH, PTO 10 AMP
(Superseded to 597520401)

$100.99

$

In Stock, Qty 5

0

31

Husqvarna 539103178

CAP, IGNITION SWITCH NUT

$4.99

$

Usually ships in 3-10 days

0

32

Husqvarna 539990209

BOLT 5/16-18 x 1 HEX HD

$1.99

$

Usually ships in 3-10 days

0

33

Husqvarna 539990188

WASHER 5/16 SAE FLAT
(Superseded to 819111116)

$3.99

$

In Stock, Qty 17

0

34

Husqvarna 539990187

WASHER 5/16 SLW
(Superseded to 596238801)

$3.99

$

In Stock, only 4 left!

0

35

Husqvarna 574822701

SCREW 10-24 x ¾ SKT HD

$4.99

$

In Stock, Qty 6

0

36

Husqvarna 539976977

NUT 10-24 HEX NYLOC

$

$

Not available

37

Husqvarna 539132624

KNOB

$7.99

$

In Stock, Qty 6

0

38

Husqvarna 574207001

CABLE, THROTTLE

$53.99

$

In Stock, only 3 left!

0

39

Husqvarna 574439601

NUT, TOGGLE

$10.99

$

In Stock, only 2 left!

0

40

Husqvarna 574455501

KEY

$6.99

$

Usually ships in 3-10 days

0

41

Husqvarna 525612801

SCREW 3/8-16 x 1 HEX HD

$

$

Not available
