PRO2.8i (PRO28I-3001) - Kohler PRO 2,800 Watt Inverter Generator Magneto Parts Diagram

PRO 2,800 Watt Inverter Generator

Magneto Parts Diagram

  • Title

1

Kohler 33 100 13-S

NUT

$5.49

$

Usually ships in 2-5 days

0

2

Kohler 33 468 07-S

WASHER

$3.99

$

Usually ships in 2-5 days

0

3

Kohler 33 173 03-S

CAP, PLUG ASSEMBLY

$24.99

$

Usually ships in 2-5 days

0

4

Kohler 33 099 02-S

SWITCH, OIL LEVEL GAUGE ASSEMBLY

$83.99

$

Usually ships in 2-5 days

0

5

Kohler 25 086 478-S

SCREW - BOLT FLANGE

$3.99

$

Usually ships in 2-5 days

0

6

Kohler 33 126 05-S

BRACKET

$4.99

$

Usually ships in 2-5 days

0

7

Kohler 33 519 01-S

COIL, IGNITION ASSEMBLY

$88.99

$

Usually ships in 2-5 days

0

8

Kohler 25 086 529-S

SCREW - BOLT

$3.99

$

Usually ships in 2-5 days

0

9

Kohler 33 177 01-S

TRIGGER ASSEMBLY - COIL PULSER

$112.99

$

Usually ships in 2-5 days

0

10

Kohler 25 086 479-S

SCREW - PAN HEAD

$3.99

$

Usually ships in 2-5 days

0

11

Kohler 33 468 06-S

WASHER, PLATE

$3.99

$

Usually ships in 2-5 days

0

12

Kohler 33 518 02-S

LEAD, WIRE SUB-LEAD

$6.49

$

Usually ships in 2-5 days

0

13

Kohler 33 313 03-S

GROMMET

$6.99

$

Usually ships in 2-5 days

0

14

Kohler 33 584 01-S

MODULE - C.D.I. UNIT ASSEMBLY

$367.99

$

Usually ships in 2-5 days

0

15

Kohler 25 086 528-S

SCREW - TAPPING

$3.99

$

Usually ships in 2-5 days

0

16

Kohler 33 468 09-S

WASHER, PLATE

$3.99

$

Usually ships in 2-5 days

0
