PR GT 2046 A - Poulan Pro Garden Tractor (2001) Ground Drive Parts Diagram

Lawn Tractor

Ground Drive Parts Diagram

  • Title
1

Electrolux/AYP 9858M1

Key, Woodruff

$

$

Not available

3

Electrolux/AYP 7563R

Washer, Thrust, Axle
(Superseded to 532007563)

$8.99

$

In Stock, only 1 left!

0

4

Electrolux/AYP 17490508

Screw Thdrol 5/16-18 x 3/4
(Superseded to 817490508)

$6.49

$

Usually ships in 3-10 days

0

5

Electrolux/AYP 73680600

Nut, Crownlock 3/8-16
(Superseded to 873680600)

$3.99

$

Usually ships in 3-10 days

0

6

Electrolux/AYP 76020412

Pin, Cotter
(Superseded to 596029501)

$3.99

$

Usually ships in 3-10 days

0

7

Electrolux/AYP 149176

Wheel, Hub Assembly
(Superseded to 532634692)

$42.99

$

Usually ships in 3-10 days

0

8

Electrolux/AYP 12000034

Klip, Ring
(Superseded to 812000034)

$

$

Not available

9

Electrolux/AYP 140080

Bolt, Hub
(Superseded to 532140080)

$3.99

$

Usually ships in 3-10 days

0

10

Electrolux/AYP 142509

Disc, Brake
(Superseded to 532142509)

$

$

Not available

11

Electrolux/AYP 136927

Yoke, Brake Disc
(Superseded to 532136927)

$

$

Not available

12

Electrolux/AYP 73750800

Nutlock 1/2-20 Unf
(Superseded to 583612501)

$2.99

$

Usually ships in 3-10 days

0

13

Electrolux/AYP 139419

Washer, Special
(Superseded to 532139419)

$6.49

$

Usually ships in 3-10 days

0

14

Electrolux/AYP 138901

Bushing
(Superseded to 532138901)

$6.49

$

Usually ships in 3-10 days

0

15

Electrolux/AYP 19131316

Washer 13/32 x 13/16 x 16 Ga.
(Superseded to 596565301)

$3.99

$

In Stock, Qty 20+

0

16

Electrolux/AYP 143012

Set, Screw 1/4-28 x 3/4
(Superseded to 532143012)

$2.99

$

Usually ships in 3-10 days

0

17

Electrolux/AYP 126909X

Spring
(Superseded to 532126909)

$5.99

$

Usually ships in 3-10 days

0

18

Electrolux/AYP 137104

Lever, Brake
(Superseded to 532137104)

$

$

Not available

19

Electrolux/AYP 136926

Cam, Brake Disc
(Superseded to 532136926)

$

$

Not available

21

Electrolux/AYP 23260412

Screw, Flat Head 1/4-28 x 3/4
(Superseded to 823260412)

$3.99

$

Usually ships in 3-10 days

0

22

Electrolux/AYP 633A109

Gearshift, Lever Assembly
(Superseded to 532124863)

$

$

Not available

23

Electrolux/AYP 106932X

Knob
(Superseded to 532106932)

$7.99

$

In Stock, Qty 5

0

24

Electrolux/AYP 136925

Support, Puck Brake
(Superseded to 532136925)

$

$

Not available

25

Electrolux/AYP 136923

Puck, Brake Top
(Superseded to 532136923)

$

$

Not available

26

Electrolux/AYP 137552

Spring, Return
(Superseded to 532137552)

$

$

Not available

27

Electrolux/AYP 17490528

Screw, Hex Wsh Thd. 5/16-18 x 1-3/4
(Superseded to 817490528)

$4.99

$

Usually ships in 3-10 days

0

28

Electrolux/AYP 73350600

Nut, Hex Jam 3/8-16
(Superseded to 873220600)

$6.49

$

In Stock, only 2 left!

0

29

Electrolux/AYP 137213

Brake, Rod
(Superseded to 532137213)

$21.99

$

Usually ships in 3-10 days

0

30

Electrolux/AYP 19131616

Washer 13/32 x 1 x 16 Ga.
(Superseded to 819131612)

$6.49

$

Usually ships in 3-10 days

0

34

Electrolux/AYP 71673

Cap, Plunger
(Superseded to 532071673)

$5.99

$

Usually ships in 3-10 days

0

35

Electrolux/AYP 137648

Rod, Parking Brake
(Superseded to 532137648)

$11.99

$

In Stock, only 1 left!

0

36

Electrolux/AYP 149412

Spring, Drive Ground
(Superseded to 532149412)

$

$

Not available

37

Electrolux/AYP 121749X

Washer 25/32 x 1-1/4 x 16 Ga.
(Superseded to 532121749)

$3.49

$

Usually ships in 3-10 days

0

38

Electrolux/AYP 150035

Nyliner
(Superseded to 532150035)

$4.99

$

Usually ships in 3-10 days

0

39

Electrolux/AYP 74321016

Screw, Fin. #10-24 x 1
(Superseded to 874321016)

$

$

Not available

40

Electrolux/AYP 5304J

Actuator, Interlock Switch
(Superseded to 532178575)

$

$

Not available

41

Electrolux/AYP 73931000

Nut Centerlock 10-24-Umc
(Superseded to 873931000)

$6.49

$

Usually ships in 3-10 days

0

42

Electrolux/AYP 8883R

Cover, Pedal
(Superseded to 532008883)

$6.49

$

Usually ships in 3-10 days

0

46

Electrolux/AYP 145170

Retainer, Spring
(Superseded to 532145170)

$4.99

$

Usually ships in 3-10 days

0

47

Electrolux/AYP 138228

Clutch Rod
(Superseded to 532138228)

$12.99

$

Usually ships in 3-10 days

0

48

Electrolux/AYP 72110612

Bolt, Carriage 3/8-16 x 1-1/2 Gr. 5
(Superseded to 872110612)

$6.49

$

Usually ships in 3-10 days

0

50

Electrolux/AYP 131494

Pulley, Idler, Flat
(Superseded to 597025001)

$26.99

$

In Stock, Qty 7

0

51

Electrolux/AYP 73800600

Nut, Crownlock 3/8-16 UNC
(Superseded to 873680600)

$3.99

$

Usually ships in 3-10 days

0

52

Electrolux/AYP 139123

Pulley, Idler, Grooved
(Superseded to 532139123)

$37.99

$

In Stock, only 1 left!

0

53

Electrolux/AYP 207J

Washer,Hardened
(Superseded to 532000207)

$6.49

$

Usually ships in 3-10 days

0

54

Electrolux/AYP 161590

Clutch, Arm Assembly
(Superseded to 532161590)

$18.99

$

Usually ships in 3-10 days

0

55

Electrolux/AYP 105706X

Bearing, Idler
(Superseded to 532105706)

$7.49

$

Usually ships in 3-10 days

0

56

Electrolux/AYP 137153

V-Belt
(Superseded to 532137153)

$72.99

$

In Stock, only 1 left!

0

57

Electrolux/AYP 141756

Bracket, Shift Rod, Hi-Lo
(Superseded to 532141756)

$

$

Not available

59

Electrolux/AYP 122253X

Shift Rod, Hi-Lo
(Superseded to 532122253)

$14.99

$

Usually ships in 3-10 days

0

60

Electrolux/AYP 122268X

Spring Clip, Connecting Link
(Superseded to 532122268)

$6.49

$

Usually ships in 3-10 days

0

61

Electrolux/AYP 137524

Pulley, Transaxle

$

$

Not available

62

Electrolux/AYP 10040700

Washer, Lock 7/16
(Superseded to 810040700)

$3.99

$

In Stock, Qty 20+

0

63

Electrolux/AYP 74760720

Bolt, Fin Hex 7/16-14 x 1-1/4
(Superseded to 874780720)

$6.99

$

Usually ships in 3-10 days

0

64

Electrolux/AYP 154752

Shaft, Clutch/Brake Pedal
(Superseded to 532154752)

$

$

Not available

65

Electrolux/AYP 67609

Bolt, Shoulder
(Superseded to 532179613)

$6.49

$

In Stock, only 2 left!

0

66

Electrolux/AYP 140296

Washer,Hardened
(Superseded to 532140296)

$6.99

$

In Stock, only 1 left!

0

67

Electrolux/AYP 19131312

Washer, Flat
(Superseded to 596133201)

$6.99

$

In Stock, only 2 left!

0

68

Electrolux/AYP 5142H

Pin, Roll
(Superseded to 532437620)

$4.99

$

Usually ships in 3-10 days

0

69

Electrolux/AYP 136327

Hub, Cover
(Superseded to 532136327)

$6.49

$

Usually ships in 3-10 days

0

117

Murray 73900600

Nut, Lock Flg. 3/8-16 Unc

$

$

Not available
