PPB 200 - Poulan String Trimmer (2006-12) Shaft Parts Diagram

String Trimmer

Shaft Parts Diagram

  • Title

1

Electrolux/AYP 530015805

Screw-alignment
(Superseded to 530015886)

$6.49

$

In Stock, only 3 left!

0

2

Electrolux/AYP 530015886

Screw

$6.49

$

In Stock, only 3 left!

0

3

Electrolux/AYP 530057983

Hsg.-Throttle-right

$

$

Not available

4

Electrolux/AYP 530016326

Screw-Cable Ret.

$

$

Not available

5

Electrolux/AYP 530057984

Hsg.-Throttle-left

$

$

Not available

6

Electrolux/AYP 530058843

Assy-Wire

$

$

Not available

7

Electrolux/AYP 530069572

Kit-Switch

$9.49

$

In Stock, only 3 left!

0

8

Electrolux/AYP 530058759

Trigger-Throttle
(Superseded to 545017701)

$

$

Not available

9

Electrolux/AYP 530058583

Assy-Handle

Note: (Incl. 10,11)

$6.99

$

Usually ships in 3-10 days

0

10

Electrolux/AYP 530015786

Bolt-Handle

$4.99

$

In Stock, only 4 left!

0

11

Electrolux/AYP 530016152

Wingnut
(Superseded to 530401992)

$2.49

$

In Stock, only 1 left!

0

12

Electrolux/AYP 530071791

Kit-Upper Shaft
(Superseded to 575260201)

Note: (Incl. Flex, clamp & 13)

$37.99

$

In Stock, only 1 left!

0

13

Electrolux/AYP 530016344

Screw

$

$

Not available

14

Electrolux/AYP 530057554

Bracket-Shield

$6.49

$

In Stock, only 2 left!

0

15

Electrolux/AYP 530096099

Gearbox

$53.99

$

In Stock, only 2 left!

0

16

Electrolux/AYP 530096218

Shaft-Flex (lower)
(Superseded to 545173003)

$10.99

$

In Stock, only 2 left!

0

17

Electrolux/AYP 530071790

Kit-Lower Shaft Assy.

$

$

Not available

18

Electrolux/AYP 530016014

Screw

$6.49

$

In Stock, only 3 left!

0

19

Electrolux/AYP 530016224

Screw

$4.99

$

In Stock, Qty 5

0

20

Electrolux/AYP 530052285

Limiter-Line

$3.99

$

Usually ships in 3-10 days

0

21

Electrolux/AYP 530015814

Screw

$6.49

$

In Stock, Qty 16

0

22

Electrolux/AYP 530015820

Bolt

$4.99

$

In Stock, only 1 left!

0

23

Electrolux/AYP 530016152

Wingnut
(Superseded to 530401992)

$2.49

$

In Stock, only 1 left!

0

24

Electrolux/AYP 530071765

Kit-Shield Assy.
(Superseded to 545081001)

Note: (incl. 20,21)

$27.99

$

Usually ships in 3-10 days

0

25

Electrolux/AYP 952711581

Accy-Cutting Head
(Superseded to 952711550)

Note: (Incl. 26-29)

$

$

Not available

26

Electrolux/AYP 530095772

Assy-Hub/Arbor

$

$

Not available

27

Electrolux/AYP 530053241

Spring-Return

$

$

Not available

28

Electrolux/AYP 530401957

Retainer-Spool

$4.99

$

In Stock, only 4 left!

0

29

Electrolux/AYP 952711580

Accy-Wound Spool
(Superseded to 952711551)

$

$

Not available

29

Electrolux/AYP 545123431

Operator Manual

Note: Not Shown

$4.99

$

Usually ships in 3-10 days

0

29

Electrolux/AYP 530055350

Decal-Shaft Warning

Note: Not Shown

$

$

Not available

29

Electrolux/AYP 530056221

Decal-Upper Shaft Warning

Note: Not Shown

$

$

Not available
