PP RT8 KA - Poulan Tiller (1995) MAINFRAME, LEFT SIDE Parts Diagram

Tiller

MAINFRAME, LEFT SIDE Parts Diagram

  • Title

1

Electrolux/AYP 532106160

O-Ring

$6.49

$

Usually ships in 3-10 days

0

2

Electrolux/AYP 810040600

Washer, Lock 3/8
(Superseded to 539990118)

$1.99

$

Usually ships in 3-10 days

0

3

Electrolux/AYP 873220600

Nut, Hex 3/8-16

$6.49

$

In Stock, only 2 left!

0

4

Electrolux/AYP 874930572

Bolt, Hex Head 5/16-18 x 4-1/2

$3.99

$

Usually ships in 3-10 days

0

5

Electrolux/AYP 532124963

Pin, Roll
(Superseded to 532002882)

$

$

Not available

6

Electrolux/AYP 532110111

Lever, Shift

$18.99

$

Usually ships in 3-10 days

0

7

Electrolux/AYP 872110404

Bolt, Carriage 1/4-20 x 1/2 Grade 5

$9.49

$

Usually ships in 3-10 days

0

8

Electrolux/AYP 532008700

Plate, Shift Indicator

$4.99

$

In Stock, only 1 left!

0

9

Electrolux/AYP 532086777

Screw, Hex Washer Head, Slotted #10-24 x 1/2
(Superseded to 532750097)

$4.99

$

In Stock, Qty 16

0

10

Electrolux/AYP 532009484

Clip

$6.49

$

In Stock, only 4 left!

0

11

Electrolux/AYP 810040400

Washer, Lock 1/4
(Superseded to 596029801)

$3.99

$

In Stock, only 2 left!

0

12

Electrolux/AYP 873220400

Nut, Hex 1/4-20
(Superseded to 532050675)

$6.49

$

In Stock, only 1 left!

0

13

Electrolux/AYP 823230506

Screw, Set, Hex 5/16-18 x 3/8

$4.99

$

In Stock, only 2 left!

0

14

Electrolux/AYP 532008382

Spacer, Split

$

$

Not available

15

Electrolux/AYP 819111116

Washer 11/32 x 11/16 x 16 Gauge
(Superseded to 596204101)

$3.99

$

In Stock, Qty 11

0

16

Electrolux/AYP 532100473

Sheave, Transmission

$

$

Not available

17

Electrolux/AYP 873220500

Nut, Hex 5/16-18

$6.49

$

Usually ships in 3-10 days

0

18

Electrolux/AYP 532008381

Spacer

$2.99

$

Usually ships in 3-10 days

0

19

Electrolux/AYP 532002649

Key, Square 3/16 x 1-1/8

$6.99

$

In Stock, only 1 left!

0

20

Electrolux/AYP 532004914

Key, Square

$2.99

$

Usually ships in 3-10 days

0

21

Electrolux/AYP 532139155

Spacer, Split .523 x .718 x 2

$6.99

$

Usually ships in 3-10 days

0

22

Electrolux/AYP 532104214

Nut, Cap 5/16-18

$4.99

$

Usually ships in 3-10 days

0

23

Electrolux/AYP 532005015

Tire

$145.99

$

In Stock, only 2 left!

0

Electrolux/AYP 532005014

Rim

$169.99

$

Usually ships in 3-10 days

0

Electrolux/AYP 532124718

Tire Valve
(Superseded to 532065139)

$9.99

$

In Stock, only 1 left!

0

24

Electrolux/AYP 532004929

Rivet, Drilled

$7.49

$

Usually ships in 3-10 days

0

25

Electrolux/AYP 532124961

Clip, Hairpin
(Superseded to 532004921)

$6.49

$

In Stock, only 2 left!

0

26

Electrolux/AYP 532144565

Guard, Belt

$

$

Not available

27

Electrolux/AYP 532138399

V-Belt

$60.99

$

Usually ships in 3-10 days

0

28

Electrolux/AYP 532104680

Pulley, Idler
(Superseded to 532004371)

$

$

Not available

29

Electrolux/AYP 812000032

Ring, Klip

$7.49

$

Usually ships in 3-10 days

0

30

Electrolux/AYP 532105611

Bracket, Idler
(Superseded to 532159229)

$

$

Not available

31

Electrolux/AYP 874770844

Bolt, Hex Head 1/2-20 x 2-3/4

$

$

Not available

32

Electrolux/AYP 532139401

Shaft, Idler Arm

$14.99

$

In Stock, only 4 left!

0

33

Electrolux/AYP 819171616

Washer
(Superseded to 596040101)

$3.99

$

In Stock, Qty 20+

0

34

Electrolux/AYP 532004368

Sheave, Engine

$14.99

$

Usually ships in 3-10 days

0

35

Electrolux/AYP 532140062

Cap, Plunger

$6.49

$

Usually ships in 3-10 days

0
