PP 455 - Poulan Pro Chainsaw Cylinder and Piston Parts Diagram

Chainsaw

Cylinder and Piston Parts Diagram

  • Title

1

Poulan 507431705

Screw

$

$

Not available

2

Poulan 507431640

Washer

$

$

Not available

3

Poulan 507476339

Module & Switch Wire Ass'y.

$

$

Not available

4

Poulan 507433248

Switch Wire

$

$

Not available

5

Poulan 507430694

Sleeve

$

$

Not available

6

Poulan 952030150

Spark Plug

$3.99

$

In Stock, Qty 20+

0

7

Poulan 507476096

Spark Plug Boot & Clip

$

$

Not available

8

Poulan 507433473

Cylinder Base Gasket

$

$

Not available

9

Poulan 507431655

Nut

$

$

Not available

10

Poulan 507431675

Screw

$1.49

$

Usually ships in 3-10 days

0

11

Poulan 507475623

Grounding Switch

$

$

Not available

12

Poulan 507432302

Washer

$3.99

$

In Stock, only 1 left!

0

13

Poulan 530038387

Switch Plate

$

$

Not available

14

Poulan 507475356

Decompression Valve

$

$

Not available

15

Poulan 507431706

Washer

$

$

Not available

16

Poulan 507431691

Screw

$

$

Not available

17

Poulan 507430684

Muffler Gasket

$

$

Not available

18

Poulan 5074759848

Muffler Body

$

$

Not available

19

Poulan 507433096

Muffler Channel

$6.49

$

In Stock, only 1 left!

0

20

Poulan 507433104

Muffler Screen

$

$

Not available

21

Poulan 5074764298

Muffler Cover Ass'y.
(Superseded to 545145415)

$

$

Not available

22

Poulan 5074761068

Heat Shield Ass'y.

$

$

Not available

23

Poulan 507431686

Lockwasher

$2.49

$

Usually ships in 3-10 days

0

24

Poulan 530015718

Screw

$

$

Not available

25

Poulan 507430993

Screw

$

$

Not available

26

Poulan 507431683

Lockwasher

$1.49

$

Usually ships in 3-10 days

0

27

Poulan 507430835

Spacer

$

$

Not available

28

Poulan 5074760748

Muffler Ass'y.

Note: (Incl. 17-27)

$

$

Not available

29

Poulan 507433475

Wrist Pin

$12.99

$

Usually ships in 3-10 days

0

30

Poulan 507476558

Piston & Rings

$

$

Not available

31

Poulan 507433476

Retainer

$4.99

$

Usually ships in 3-10 days

0

32

Poulan 507476508

Piston Ring Set

$

$

Not available

33

Poulan 507476507

Cylinder & Piston Kit

$

$

Not available
