PP 333 - Poulan String Trimmer (2009-05) Shaft Parts Diagram

String Trimmer

Shaft Parts Diagram

  • Title

1

Electrolux/AYP 545191801

Assy-Switch Wire

$

$

Not available

2

Electrolux/AYP 545008077

Kit - Trigger

Note: (Incl. 6)

$

$

Not available

3

Electrolux/AYP 545187602

Housing -Throttle (RH)

$14.99

$

Usually ships in 3-10 days

0

4

Electrolux/AYP 530016449

Screw M4

$6.49

$

In Stock, only 2 left!

0

5

Electrolux/AYP 530015805

Screw 10-14 x 1/2
(Superseded to 530015886)

$6.49

$

In Stock, only 3 left!

0

6

Electrolux/AYP 545190001

Spring-Trigger

$3.49

$

In Stock, only 4 left!

0

7

Electrolux/AYP 545199301

Cable - Throttle

$

$

Not available

8

Electrolux/AYP 545187502

Housing-Throttle (LH)

$14.99

$

In Stock, only 1 left!

0

9

Electrolux/AYP 545008040

Kit-Switch
(Superseded to 545049309)

$4.99

$

Usually ships in 3-10 days

0

10

Electrolux/AYP 530015886

Screw 10-14 x 13/16

$6.49

$

In Stock, only 3 left!

0

11

Electrolux/AYP 530058563

Clamp - Bracket

$4.99

$

In Stock, only 1 left!

0

12

Electrolux/AYP 545024501

Clamp - Handlebar

$6.99

$

In Stock, only 4 left!

0

13

Electrolux/AYP 530071974

Kit - Handlebar

$27.99

$

Usually ships in 3-10 days

0

14

Electrolux/AYP 545113301

Clamp - Upper Harness

$6.49

$

Usually ships in 3-10 days

0

15

Electrolux/AYP 545056601

Clamp - Lower Harness

$4.99

$

In Stock, only 3 left!

0

16

Electrolux/AYP 530015940

Screw - 10-14 x .095

$6.49

$

In Stock, Qty 8

0

17

Electrolux/AYP 545003366

Kit - Upper Drive Shaft
(Superseded to 575260201)

Note: (Incl. 18)

$37.99

$

In Stock, only 1 left!

0

18

Electrolux/AYP 530016344

Screw - 12-24 x .480

$

$

Not available

19

Electrolux/AYP 545132002

Flexshaft - lower

$7.49

$

In Stock, only 1 left!

0

20

Electrolux/AYP 530094408

Shoulder Strap
(Superseded to 530094417)

$

$

Not available

21

Electrolux/AYP 545180883

Kit - Lower Drive Shaft

$

$

Not available

22

Electrolux/AYP 530015775

Screw - 8-16 x .593

$6.49

$

In Stock, only 2 left!

0

23

Electrolux/AYP 530016014

Screw - 12-24 x .960

$6.49

$

In Stock, only 3 left!

0

24

Electrolux/AYP 545150701

Bracket - Shield SST

$5.99

$

In Stock, only 2 left!

0

25

Electrolux/AYP 530096100

Assy - Gearbox 1" Brushcutter

$62.99

$

Usually ships in 3-10 days

0

26

Electrolux/AYP 530016312

Screw 10-24

$6.49

$

In Stock, only 3 left!

0

27

Electrolux/AYP 530095815

Dust cup

$11.99

$

In Stock, Qty 6

0

28

Electrolux/AYP 530071383

Kit - Metal Blade Shield

$14.99

$

Usually ships in 3-10 days

0

29

Electrolux/AYP 530055892

Assy. - Blade
(Superseded to 577614209)

$34.99

$

In Stock, only 1 left!

0

30

Electrolux/AYP 530095816

Washer

$10.99

$

In Stock, Qty 5

0

31

Electrolux/AYP 530016240

Washer - Belleville

$6.49

$

In Stock, only 1 left!

0

32

Electrolux/AYP 530015793

Nut - Flange (L.H.)

$6.49

$

In Stock, Qty 5

0

33

Electrolux/AYP 530016152

Wingnut 1/4-20
(Superseded to 530401992)

$2.49

$

In Stock, only 1 left!

0

34

Electrolux/AYP 530071919

Kit - Shield

Note: (Incl. 33,35,36,37)

$27.99

$

Usually ships in 3-10 days

0

35

Electrolux/AYP 530052286

Line Limiter

$

$

Not available

36

Electrolux/AYP 530015814

Screw - 10-14 x 3/4

$6.49

$

In Stock, Qty 16

0

37

Electrolux/AYP 530015820

Bolt - 1/4-20 x 1-1/4

$4.99

$

In Stock, only 1 left!

0

38

Electrolux/AYP 545049401

Head - Fixed Line
(Superseded to 545053902)

$37.99

$

In Stock, only 3 left!

0

39

Electrolux/AYP 952711635

Line - Accy. 12 pcs. (.115 Round)

$

$

Not available

40

Electrolux/AYP 545049501

Cap - Fixed Line

$9.99

$

Usually ships in 3-10 days

0

40

Electrolux/AYP 545186843

Manual - Operators

Note: Not Shown

$3.99

$

Usually ships in 3-10 days

0

40

Electrolux/AYP 545176003

Decal-Shaft Warning (lower)

Note: Not Shown

$

$

Not available

40

Electrolux/AYP 545167716

Decal-Shaft Warning (upper)

Note: Not Shown

$

$

Not available
