PP 1136 A - Poulan Pro Lawn Tractor MOWER LIFT LEVER Parts Diagram

Lawn Tractor

MOWER LIFT LEVER Parts Diagram

  • Title

1

Poulan 532126470

Clip, Insulated (AYP part number)

$3.99

$

Usually ships in 3-10 days

0

2

Poulan 532122018

Bracket, Mower Clutch (AYP part number)

$

$

Not available

3

Poulan 874780408

Bolt, Fin. Hex 1/4-20 Unc x 1/2 Gr.5 (AYP part number)
(Superseded to 74780408)

$1.49

$

Usually ships in 3-10 days

0

4

Poulan 873680600

Nut, Crownlock 3/8-16 UNC
(Superseded to 596322601)

$3.99

$

In Stock, only 4 left!

0

5

Poulan 532123417

Assembly, Clutch Lever (AYP part number)
(Superseded to 532145187)

$

$

Not available

6

Poulan 532106451

Bolt, Shoulder (AYP part number)

$2.99

$

Usually ships in 3-10 days

0

7

Poulan 532123491

Assembly, Mower Clutch Arm (AYP part number)

$

$

Not available

8

Poulan 874760636

Bolt, Hex 3/8-16 UNC x 2 1/4 (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

9

Poulan 532121930

Assembly, Bellcrank Lift (AYP part number)

$11.99

$

Usually ships in 3-10 days

0

10

Poulan 876020412

Pin, Cotter 1/8 x 3/4 (AYP part number)
(Superseded to 596029501)

$3.99

$

In Stock, only 1 left!

0

11

Poulan 819131316

Washer, 13/32 x 13/16 x 16 Ga. (AYP part number)

$4.99

$

In Stock, Qty 5

0

12

Poulan 532122027

Grip, Handle (AYP part number)

$

$

Not available

13

Poulan 532127028

Assembly, Lift Handle (AYP part number)

$

$

Not available

14

Poulan 532123496

Spring, Compression (AYP part number)

$2.99

$

Usually ships in 3-10 days

0

15

Poulan 819131212

Washer, 13/32 x 3/4 x 12 Ga. (AYP part number)
(Superseded to 19131212)

$2.99

$

Usually ships in 3-10 days

0

16

Poulan 532004921

Retainer, Spring (AYP part number)

$6.49

$

In Stock, only 2 left!

0

17

Poulan 532123654

Link, Front Lift (AYP part number)
(Superseded to 123654X)

$

$

Not available

18

Poulan 532007078

Threaded, Trunnion 3/8-16 (AYP part number)
(Superseded to 532142028)

$

$

Not available

19

Poulan 873350600

Nut, Hex Jam 3/8 x 16 UNC (AYP part number)
(Superseded to 873220600)

$6.49

$

In Stock, only 2 left!

0

20

Poulan 874760644

Bolt, Fin. Hex 3/8-16 UNC x 2 3/4 (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

21

Poulan 817490508

Screw, Hex Thdrol. 5/16-18 x 1/2 (AYP part number)

$6.49

$

Usually ships in 3-10 days

0

22

Poulan 532121929

Bracket, Mower Height (AYP part number)

$

$

Not available

23

Poulan 876020416

Pin, Cotter 1/8 x 1 (AYP part number)

$3.99

$

Usually ships in 3-10 days

0

24

Poulan 819171616

Washer 17/32 x 1 x 16 Ga. (AYP part number)
(Superseded to 596040101)

$3.99

$

In Stock, Qty 20+

0

25

Poulan 532121933

Tube, Spacer (AYP part number)

$

$

Not available

26

Poulan 532121934

Rod, Mower Lift (AYP part number)
(Superseded to 532141470)

$

$

Not available

27

Poulan 819131316

Washer, 13/32 x 13/32 x 16 Ga. (AYP part number)

$4.99

$

In Stock, Qty 5

0

28

Poulan 532106932

Knob (AYP part number)

$7.99

$

In Stock, Qty 5

0

29

Poulan 876020312

Pin, Cotter 3/32x3/4 (AYP part number)
(Superseded to 876020308)

$

$

Not available

30

Poulan 532123671

Link, Mower Clutch (AYP part number)

$10.99

$

Usually ships in 3-10 days

0

31

Poulan 873680400

Nut, Crownlock 1/4-20 (AYP part number)
(Superseded to 586668901)

$4.99

$

In Stock, Qty 16

0
