PB 195H42 LT (960420107-03) - Poulan Pro Lawn Tractor (2010-05) Engine Parts Diagram

Lawn Tractor

Engine Parts Diagram

  • Title

1

Engine B&S Model No. 31P677-1373-B1

$

$

Not available

2

Electrolux/AYP 532137352

Muffler

$45.99

$

In Stock, only 3 left!

0

9

Electrolux/AYP 532194320

Keeper Belt Engine
(Superseded to 596501502)

$11.99

$

In Stock, Qty 5

0

12

Electrolux/AYP 532405471

Pulley Engine
(Superseded to 586478501)

$40.99

$

In Stock, only 2 left!

0

15

Electrolux/AYP 532407545

Tank Fuel 1.50
(Superseded to 581289901)

$87.99

$

In Stock, only 1 left!

0

18

Electrolux/AYP 532430220

Cap Fuel
(Superseded to 581075501)

$26.99

$

Usually ships in 3-10 days

0

20

Electrolux/AYP 532170545

Control Throttle/Choke
(Superseded to 583045801)

$40.99

$

Usually ships in 3-10 days

0

21

Electrolux/AYP 532416358

Screw #10 x 0.750
(Superseded to 596321701)

$3.99

$

In Stock, Qty 15

0

28

Electrolux/AYP 532401137

Fuel Line

$14.99

$

Usually ships in 3-10 days

0

29

Electrolux/AYP 532137180

Spark Arrester Kit
(Superseded to 532121851)

$

$

Not available

37

Electrolux/AYP 532123487

Clamp Hose

$7.49

$

In Stock, only 4 left!

0

42

Electrolux/AYP 810040700

Washer Lock 7/16
(Superseded to 539990247)

$3.99

$

In Stock, Qty 20+

0

45

Electrolux/AYP 873510400

Nut Keps Hex 1/4-20 unc
(Superseded to 873640400)

$

$

Not available

69

Electrolux/AYP 532165291

Gasket
(Superseded to 532272293)

$12.99

$

Usually ships in 3-10 days

0

79

Electrolux/AYP 532192334

Screw Socket Hd 5/16-18 x .75
(Superseded to 596134201)

$3.99

$

In Stock, Qty 13

0

84

Electrolux/AYP 817060620

Screw 3/8-16 x 1-1/4

$7.49

$

In Stock, Qty 11

0

85

Electrolux/AYP 532173937

Bolt Hex 7/16-20 x 4 x Gr. 5-1.5
(Superseded to 501606501)

$4.99

$

In Stock, only 1 left!

0

90

Electrolux/AYP 817000616

Screw 3/8-16 x 1.0

$7.49

$

In Stock, only 3 left!

0

96

Electrolux/AYP 819091416

Washer 9/32 x 7/8 x 16 Ga.

$6.49

$

Usually ships in 3-10 days

0

97

Electrolux/AYP 817670412

Screw 1/4-20 x 3/4

$6.49

$

Usually ships in 3-10 days

0

122

Electrolux/AYP 532421922

Extension Drain Oil

$40.99

$

In Stock, Qty 8

0
