MZ (MZ Magnum) - Bad Boy Zero-Turn Mower (2019) SEAT PAN & COVERS Parts Diagram

Zero-Turn Mower

SEAT PAN & COVERS Parts Diagram

  • Title

1

Bad Boy 013-2050-00

1/4-20 Nylon Insert flange Nut

$1.49

$

In Stock, only 2 left!

0

2

Bad Boy 013-5019-00

10-24 Nylon Insert Locknut Zinc Orange Nylon

$0.99

$

In Stock, only 2 left!

0

3

Bad Boy 013-8049-00

5/16" Nylon Flange Nut

$0.99

$

In Stock, Qty 17

0

4

Bad Boy 013-9001-00

1/4-20 Hex Flange Nuts Zinc w/Serrations

$0.99

$

In Stock, only 4 left!

0

5

Bad Boy 014-3317-00

2017 MZ Cooler Cover

$81.99

$

Usually ships in 0 days

0

6

Bad Boy 018-1080-00

12-24x 1/2 HWH Bolt

$2.49

$

Usually ships in 4-7 days

0

7

Bad Boy 018-2012-00

1/4" x 1/2" BS C/S 18-8 SS

$0.99

$

In Stock, only 4 left!

0

8

Bad Boy 018-5200-00

10-24 X 5/8 BS Button Head Bolt

$0.99

$

In Stock, Qty 5

0

9

Bad Boy 018-8065-00

5/16" x 1" Carriage Bolt

$0.99

$

In Stock, Qty 7

0

10

Bad Boy 018-8066-00

5/16" x 7/8" Carriage Bolt

$1.99

$

In Stock, Qty 6

0

11

Bad Boy 019-6042-00

.360ID Plastic Washer

$0.99

$

In Stock, Qty 11

0

12

Bad Boy 019-8040-00

1/4" x 3/4" Carriage Bolt

$1.99

$

In Stock, only 3 left!

0

13

Bad Boy 026-0117-00

2017 MZ Rear Plate

$83.99

$

Usually ships in 4-7 days

0

14

Bad Boy 026-2017-00

2017 MZ Seat Plate

$136.99

$

Usually ships in 4-7 days

0

15

Bad Boy 029-4010-00

Button Bumper

$1.49

$

Usually ships in 4-7 days

0

16

Bad Boy 030-3050-00

#10 x 1/2" Self Tapping Screw

$0.99

$

In Stock, Qty 9

0

17

Bad Boy 030-7042-00

5/16 x 3/4 washer head type F screw

$1.49

$

Usually ships in 4-7 days

0

18

Bad Boy 040-6080-00

Ratchet Fastener

$3.49

$

In Stock, only 3 left!

0

19

Bad Boy 055-2012-00

Universal Throttle

$27.99

$

In Stock, only 3 left!

0

20

Bad Boy 055-2013-00

Throttle Knob

$13.99

$

In Stock, only 3 left!

0

21

Bad Boy 064-8057-17

MZ Brake Cable

$27.99

$

In Stock, Qty 20+

0

22

Bad Boy 077-8073-00

Safety Switch

$11.99

$

In Stock, Qty 20+

0

23

Bad Boy 079-3417-00

MZ/ZT 2017 Floorboard

$166.99

$

Usually ships in 4-7 days

0

24

Bad Boy 081-4000-00

2017 MZ/ZT Floor Mat

$66.99

$

Usually ships in 4-7 days

0

25

Bad Boy 086-3050-19

Wiring Harness

$341.99

$

Usually ships in 4-7 days

0

26

Bad Boy 086-1202-01

Relay Block Cover Replacement Kit

$19.99

$

Usually ships in 4-7 days

0

27

Bad Boy 086-1202-19

Relay

$26.99

$

In Stock, Qty 9

0
