MZ Magnum (MZ Rambler) - Bad Boy Zero-Turn Mower (2025) UPPER FRAME Parts Diagram

Zero-Turn Mower

UPPER FRAME Parts Diagram

  • Title

1

Bad Boy 013-2050-00

1/4-20 NYL INSERT FLANGE LOCKNUT ZINC

$1.49

$

In Stock, only 2 left!

0

2

Bad Boy 013-6051-00

3/8-24 HEX NUT ZINC YELLOW

$0.99

$

In Stock, Qty 20+

0

3

Bad Boy 013-8049-00

5/16-18 NYLON INSERT FLANGE LOCKNUT ZINC

$0.99

$

In Stock, Qty 17

0

4

Bad Boy 014-8047-00

Spring Cap Cover

$2.49

$

In Stock, Qty 6

0

5

Bad Boy 018-8063-00

5/16-18 X 3/4 HEX CAP SCREW (GR.5) ZINC

$0.99

$

In Stock, only 2 left!

0

6

Bad Boy 018-8066-00

5/16-18 X 7/8 CARRIAGE BOLT ZINC

$1.99

$

In Stock, Qty 6

0

7

Bad Boy 019-6042-00

.360 ID X .983 OD X .120 THICK FLAT WASHER NYLON

$0.99

$

In Stock, Qty 11

0

8

Bad Boy 019-7040-00

1/4 USS FLAT WASHER (3/4 OD) ZINC

$0.99

$

In Stock, Qty 7

0

9

Bad Boy 019-8040-00

1/4-20 X 3/4 CARRIAGE BOLT (GR.5) ZINC

$1.99

$

In Stock, only 3 left!

0

10

Bad Boy 019-8051-00

5/16 SPLIT LOCKWASHER ZINC

$0.99

$

In Stock, only 4 left!

0

11

Bad Boy 026-2022-00

2022 Avenger Seat Plate

$102.99

$

Usually ships in 4-7 days

0

12

Bad Boy 029-4011-00

2023 Floor Board Rubber Bumper

$1.49

$

Usually ships in 4-7 days

0

13

Bad Boy 034-8045-03

Seat Spring Assembly

$34.99

$

Usually ships in 4-7 days

0

14

Bad Boy 034-8045-22

2022 Mav/HD seat spring assembly with strap

$34.99

$

Usually ships in 4-7 days

0

15

Bad Boy 054-8016-00

Choke (42" Only)

$30.99

$

In Stock, only 4 left!

0

16

Bad Boy 054-8017-00

Choke

$27.99

$

In Stock, Qty 20+

0

17

Bad Boy 070-2500-00

2025 MZ 42-48 Frame

$1025.99

$

Usually ships in 0 days

0

18

Bad Boy 070-2501-00

2025 MZ-Avenger 54-60 Frame

$1025.99

$

Usually ships in 0 days

0

19

Bad Boy 071-1000-25

2025 Magnum & Rambler Seat

$455.99

$

Usually ships in 0 days

0

20

Bad Boy 071-2100-22

2022 Avenger Seat

$604.99

$

Usually ships in 4-7 days

0

21

Bad Boy 079-3425-25

2025 MZ/Avenger Floorboard Assembly

$

$

Currently unavailable

22

Bad Boy 091-0214-00

2018 LH/RH Steering Control Decal Roll

$9.99

$

Usually ships in 4-7 days

0

23

Bad Boy 091-0339-18

2018 MZ/Magnum/ZT/MAV/Comp Out Brake Decal

$12.99

$

Usually ships in 4-7 days

0

24

Bad Boy 091-3150-00

Outlaw Warning Decal

$11.99

$

In Stock, only 2 left!

0

25

Bad Boy 091-4063-00

Flying Bulldog Front Bumper Decal

$13.99

$

Usually ships in 4-7 days

0
